| Prod Model: |
OH-0.31F |
| Dimension: |
750*450*185 |
| Air Quantity: |
19m3/Min |
| Gas-Consumption: |
3.41nm3/H |
| Power Source: |
220V 50Hz |
| Control Type: |
Two Grade |
| Heating Ability: |
3, 6000kcal/H |
| Type: |
Environmentally Diesel Furnace |
| Usage: |
Aluminum Die-casting |
| Fuel: |
Fuel |
Product Description
Detailed description:³
1.Advanced heating ability:
Because of using FE combustion mode, it won't appear hypoxia and air pollutions, heating fast,efficient, safe.
2.Nice appearance, easy operation
The application of air filter device,explosion-proof device, combustion detection equipment, overheating protection device and so on many kinds of safety device in combustion chamber top,makes operation specially safety.
3. Equipped with a variety of safety protection circuit outside:
Not only automatic operation, automatic temperature adjustment, but also optional for blower do up, down, left, right direction of adjustment, heating more prosperous.
4. The heater application scope:
apply to factory, agricultural trellis, schools, gymnasium, bath lounge, canteen, conference room, library and public places.
Technical parameter:
| heating ability | heating house area | air quantity | dimensions | oil consumption | gas consumption | power source | control type |
| OH-1.31F | 13000kcal/h | 80-120m² | 19m³/min | 750*450*185 | 1.58kg/h | 1.55Nm³/h | 220/v50hz | two grade |
| OH-2.51F | 25000kcal/h | 100-200m² | 34m³/min | 750*450*185 | 2.97kg/h | 2.91Nm³/h | 220v/50hz | two grade |
| OH-0.31F | 36000kcal/h | 130-280m² | 40m³/min | 750*450*185 | 3.48kg/h | 3.41Nm³/h | 220v/50hz | two grade |
| OH-051F | 50000kcal/h | 240-480m² | 60m³/min | 950*540*200 | 5.58kg/h | 5.47Nm³/h | 220v/50hz | two grade |
characteristics:
1. Precision temperature control.
2.Adopt top-quality insulating materials.
3. Gas, fuel fire safety and stability, burning full.
4. Automatic operation: combustion quantity, combustion temperature control, the entire process of automatic control, safety protection.
5. Suitable for various kinds of fuel gas, liquefied gas,natural gas, diesel, kerosene, etc.
Technical support:
1: 3D video guide
2: mannual book in english
3:technical drawing
4:experienced engineers' guidance
About us:
Qingdao Olympia Heat Energy Equipment Co., Ltd. is a professional manufacturer producing burners, the company in the early 1990s to learn advanced technology from Japan, created the Liaoyang Olympia Co., Ltd.,since 2003, created the need for the development of Qingdao Olympia Heat equipment Co., Ltd.....
The company mainly produces products fuel, gas, oil and gas mixing burner. Sizes from small civilian burner to large industrial burners, while the production of hot water boiler, stove, medical incinerator. The past two years, the company has developed a non-emission green energy toilet, far infrared and far infrared sauna equipment road heating equipment.
Company in Shenyang, Shanghai, Nanjing, Changchun and other cities with distribution facilities, our technical department dedicated to providing technical advice and training, adhere to honesty, novelty, quality first for business purposes, based on high technology, sufficient to attract domestic and foreign advanced technology and experience, continue to provide quality products and services.
Our products are widely used in hotels, restaurants, highways, fitness center, sauna, factories, etc., especially for non-environmentally friendly toilet sewage treatment places, by the majority of users favor. Products with environmental protection, energy saving, safe, convenient, and efficient features, has won a good business reputation and high visibility, sales network throughout the country. We warmly welcome all walks of life to discuss about consulting, visit the guide, work together for China's energy and environmental protection industry to contribute.
