Waste Garbage Incinerator with Ce Certificate
| Price: |
US $ 10500/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T,D/P,Western Union,Paypal |
| Prod Model: |
FSL-50 |
| Weight: |
3 Ton |
| Oil-Consumption(Kg/H): |
25-30 |
| Model Of Burner: |
Om-2 |
| Power Suppy: |
380V 50Hz |
| Power Of Blower(Kw): |
1.5+4 |
| Process Per Time: |
50kg |
| Process Times /Day: |
5-6 Times |
| Temperature Control: |
Automatic |
| Door Size: |
600*600 |
| Burn Room Size: |
1200*600*900 |
Product Description
Waste Disposal Garbage Harmless Treatment IncineratorImproper disposal of medical rubbish with a large number of harmful bacteria and viruses, may have a bad effect on the local environment.Our company specializes in dealing with various medical wastes .Garbage is delivered to the incinerator by the conveyor.In the process of burning , harmful gas can be transported to the high- temperature furnace of tail gas treatment through the flue.Complex and winding structure was adopted in the incinerator, which makes the residence time of flue gas in furnace excess 3s. By 1100 high temperature burning, all the bacteria and viruses are completely killed. Later the flue gas was conveyed into flue to cyclone separator and spraying device to further eliminate residual fine particles in flue gas.Finally,The chimney will release pollution-free flue gas into atmosphere.Characteristic:1. Digital display temperature, full automatic control after set temperature; 2. Stable performance and reliable operation;
3. Full burning, it can burn out the medical waste including residues, plastics, organics and so on.
Smokeless and Odorless and no pollution to the environment.
4. Large capacity, can burn big waste directly like size 70cm.
5. Using 2nd combustion technology, fully burn harmful waste gas. No black smoke, ash less.
6. The internal use materials of high temperature and corrosion resistant, safe and reliable. Application:This equipment is suitable for the hospital medical waste, life rubbish, dead animals, the villages and towns of urban garbage disposal, and various aspects non-hazardous wastes treatment.The incinerator of FSL-50 technical parameters| Burning waste | solid waste |
| Fuel | Diesel |
| Processing capacity | 50kg/time |
| Burner size | 3600mm×1420mm×2100mm |
| Blower | Power 1.5+4 |
| Door size | 600mm X 600mm |
| Running voltage | 380V 50Hz |
| Weight | About 3500kg |
The medical waste incinerator of FSL-50 standard configuration | No | Name | Amount | Specifications | Notes |
| 1 | Incinerator | 1 | Q235 steel refractories | Main part |
| 2 | The 2 combustion chamber and the combustion chamber mixed | 1 | Q235 steel refractories | Installed in the main body |
| 3 | Electric box | 1 | | The main body
|
| 4 | Combustion burner | 1 | OM-2 | The main body
|
| 5 | Second burning burner | 1 | OM-3 | |
| 7 | Blower | 1 | 3.7KW/220V/380V | The main body
|
| 8 | Thermo couple | 2 | 1100ºC | The main body
|
| 9 | Operational procedures | 1 | | The main body
|
The medical waste incinerator air exhausting | Exhaust air | The first time dedication(kg/h) | The second time dedication(kg/h) |
| SO2 | 0.279 | 0.163 |
| NOx | 0.286 | 0.219 |
| Smoke and Dust | 0,293 | 0.172 |
| Smoke blackness | <1 | <1 |
FSL series Incinerator Parameters:| ART NO | PROCESS QTY PER TIME | OIL CONSUMPTION/HOUR | CONTROL | POWER SUPPLY | FAN POWER |
| FSL-20 | 20KG | 5-10 | Automatic | 220V/50HZ | 1.5+1.5 |
| FSL-30 | 30KG | 10-15 | Automatic | 220V/50HZ | 1.5+1.5 |
| FSL-50 | 50KG | 25-30 | Automatic | 380V/50HZ | 1.5+4 |
| FSL-100 | 100KG | 30-60 | Automatic | 380V/50HZ | 4+4 |
| FSL-200 | 200KG | 50-100 | Automatic | 380V/50HZ | 4+4+4 |
