| Prod Model: |
OBH-3OB |
| Available Fuel: |
Heavy Oil, Light Oil, Natural Gas |
| Rated Oil Conbustion: |
31.4kg/H |
| Thermal Power: |
35000kcal/H |
| Function: |
Hot Water Boiler |
| Fuel: |
Oil-Fired |
| Installation: |
Assembled Boiler |
| Structure: |
Water Tube |
| Media: |
Hot Water |
| Water Circulation: |
Natural Circulation |
| Drum Placement: |
Horizontal Boiler |
| Manufacturing Level: |
A |
| Burning Style: |
Chamber Combustion Boiler |
| Usage: |
Power Station |
| Pressure: |
Pressure Atomized, Micro-Positive Pressure |
Product Description
OBH box-typed hot water boiler
Detailed introduction:1.OBH - B series central hot water unit, is the double furnace water heater units with modular design concept, output power from 300,000 Kcal/h to 2.4 million Kcal/h, has the disassembling flexible,large adapting scope and so on characters.
2.Save energy and reduce pollution
3.Noise reduction, safe and reliable | Parameters | Unit | Boiler model |
| Boilerbody | rating | MW | OBH-3OB | OBH-6OB | OBH-90B | OBH-120B | OBH-180B | OBH-240B | OBH-360B |
| thermal power | 100000kcal/h | 0.35 | O.7 | 1.05 | 1.4 | 2.1 | 2.8 | 4.2 |
| Rated working pressure | MPA | 0 | 0 | 0 | 0 | 0 | 0 | 0 |
| Rated water output temp | `C | 85 | 85 | 85 | 85 | 85 | 85 | 85 |
| Rated feed-water temp | `C | 20 | 20 | 20 | 20 | 20 | 20 | 20 |
| Circulating water volume | t/h | 12 | 24 | 36 | 48 | 72 | 96 | 144 |
| Design power | % | 91 | 90.5 | 91.2 | 91.2 | 90.8 | 91 | 91 |
| Rated oil conbustion | kg/h | 31.4 | 62.8 | 95.2 | 126.5 | 188.8 | 253 | 379.7 |
| Boiler heated area:Heating area, Already heating area | m2 | 16 | 26.98 | 38 | 56.77 | 84 | 110.47 | 159.5 |
| Available fuel | Heavy oil,light oil,natural gas |
| Combustion type | Pressure atomized, Micro-positive pressure |
| Equipment weight | kg | 680 | 1250 | 2100 | 2500 | 4500 | 5350 | 6800 |
About us: Qingdao Olympia Heat Energy Equipment Co., Ltd
Qingdao Olympia Heat Energy Equipment Co., Ltd is a professional manufacturer of burners. Sino-Japan Liaoyang Olympia Co., Ltd was founded at the beginning of 1990s through borrowing the advanced technology from Japan. Under the demand for further development, Qingdao Olympia Heat Energy Equipment Co., Ltd was established in 2003.
The company main products include burners of fuel oil, fuel gas, and mixed oil and gas including all kinds of specifications from small-size civil burners to large-scale industrial burners. Meanwhile, the company also produces heat energy equipments such as hot water boiler, air furnace, incinerator for medical purpose, etc. Nearly two years, the company also developed no-emission environmental protection and energy saving toilet, infrared sauna equipments and far-IR road-building heating equipment.
The company has set up distributions branches in large and medium cities such as Shenyang, Shanghai, Nanjing and Changchun. The company Technology Department will sincerely offer users with technical consultation and personnal training, and continue to provide users with high-quality products and services according to the operation tenet of honesty, innovation and high-grade quality, on the basis of the high technology, and through fully attracting the advanced technology and experience in China and abroad.
Products are widely used in hotels, restaurants, highway, fitness center, sauna bath, factories. etc, especially for environmental protection toilets, where no sewage treatmentWe have recieved the high praise from our customers. Company products with environmental protection, energy saving, safe, convenient and efficient characteristics, win a good business prestige and higher well-knownness, the sales network spreads all over the country.
We applaud warmly persons of various social communities to come for business negatiation and consultation or giving instructions. Let us contribute together to energy sources industry of China.
