| Prod Model: |
XB-OTS-500J |
| Controller: |
Germany Klockner-Moeller |
| Humiture Range: |
(Rt+10)~70 Degree C; 30~98%Rh |
| Humiture Uniformity: |
+/-2 Degree C; +/-3%Rh |
| Rainfall Time: |
1~9999min, Adjustable |
| Rainfall Cycle: |
1~240min, Interval Is Adjustable |
| Type: |
Xenon Aging Testing Chamber |
Product Description
Coating Industry Xenon-Lights Resistant To Climatic Testing machine Test Cabinet
Introduction:
Xenon lamp test machine is best fit to mimic natural full sunlight spectrum xenon arc lamp to reproduce the destructive waves of light of different environment, which can be an excellent material for accelerated testing light fastness and weather resistance. Can be used for the screening of new material, improvement of existing materials or evaluate material such as the change of the composition change after durability test. Industry widely used, for example: paint ink, paint, resins, plastics, printing and packaging, adhesive, car motorcycle industry, cosmetics, metal, electronic, electroplating, medicine, etc.
Xenon Weather Conditions Meter is to test the product undergone illumination/rain/condensation/temperature/humidity/wind and any other climatic changes. This aging tester mainly for the test of non-ferrous/organic/rubber/plastic and building materials. It can provide data for user to evaluate the products' properties and performance in order to improve the product qualities.
Specification:
| Model | Specifications: | Model | XB-OTS-J500 | | Inner Box Size (D×W×H) | 800×800×800mm | | Outside Dimension (D×W×H) | 1150×1350×1750mm | | Humiture Range | (RT+10)~70°C; 30~98%RH | | Humiture uniformity | ± 2°C; ± 3%RH | | Rainfall time | 1~9999min, adjustable | | Rainfall cycle | 1~240min, interval is adjustable | | Xenon lamp light | xenon long-arc lamp, 6KW±10%, 290-800nm, 1000W/m2±200 | | Heating/humidifying power | 2.0KW/2.0KW | | Sample spinning machine speed | 1~5r/ min (adjustable) | | Sample and xenon lp amdistance | 300~375mm | | Box material | Stainless Steel SUS304# | | Insulation materials | Superfine heat insulation cotton | | Insulation body | Superfine glass fabric | | Circulation system | Single cycle, centrifugal fan | | Control system | Germany KLOCKNER-MOELLER programmable controller | | Gas processing | discharger for factor and harmful gas | | Power | AC380V, three phase five wire, 10KW | | Use environment | 5°C~+30°C, ≤85%R.H | | Standard features | 1. Filtering screen viewing window; 2. Moisture proof lamp | | Security Protection | Security device for circuit break, | | high pressure of the compressure, high temperature alarm |
|
| Inner Box Size (D×W×H) | 800×800×800mm |
| Outside Dimension (D×W×H) | 1150×1350×1750mm |
| Humiture Range | (RT+10)~70°C; 30~98%RH |
| Humiture uniformity | ± 2°C; ± 3%RH |
| Rainfall time | 1~9999min, adjustable |
| Rainfall cycle | 1~240min, interval is adjustable |
| Xenon lamp light | xenon long-arc lamp, 6KW±10%, 290-800nm, 1000W/m2±200 |
| Heating/humidifying power | 2.0KW/2.0KW |
| Sample spinning machine speed | 1~5r/ min (adjustable) |
| Sample and xenon lamp distance | 300~375mm |
| Box material | Stainless Steel SUS304# |
| Insulation materials | Superfine heat insulation cotton |
| Insulation body | Superfine glass fabric |
| Circulation system | Single cycle, centrifugal fan |
| Control system | Germany KLOCKNER-MOELLER programmable controller |
| Gas processing | discharger for factor and harmful gas |
| Power | AC380V, three phase five wire, 10KW |
| Use environment | 5°C~+30°C, ≤85%R.H |
| Standard features | 1. Filtering screen viewing window; 2. Moisture proof lamp |
| Security Protection | Security device for circuit break, |
| high pressure of the compressure, high temperature alarm |
Features:
1.Inner chamber is made of advance stainless steel pate , outside skin is made of SUS304# stainless steel card pate .
2.Dynamic rotating sample frame, speed can be adjusted.
3.Using the imported intelligence temperature control instrument, with the PID adjustment ,fast auto-tuning ,can set up many kinds of technical parameters. Temperature direct digital display, reading is very convenient.
4.A filter light observation window, harmful gas vents.
5.Double metal the blackboard thermometer.
6.Variety of safety protection devices.
Design Criteria:
JIS K 6259, ASTM1149, ASTM1171, ISO1431, DIN53509, GB/T13642, GB/T 7762-2003, GB 2951
ASTM D4329,D499,D4587,D5208,G154,G53;ISO 4892-3,ISO 11507;EN 534;PREN 1062-4, BS 2782;JIS D0205;SAE J2020
Certificate:
Global safety design, use our chambers safely and with peace of mind for many years to come.
We deliver chambers that conform to international safety standards.
Our chambers conform to ISO risk assessment as well as global safety design electrical safety standards such as CE marking and EMC directive.
The production process of the test chambers :
Our Services:
We are here to help you.Services available:
Replacement manuals
Consumables and replacement parts
On-site maintenance and repair
Warranty support
Over-the-phone service support and advice
If you have an OTS chamber , we will do our best to help you in whatever way we can.
Manuals:PDF files of manuals for current models are available free.Please contact us to request a copy.Older and printed copies at additional charge.
Service repair:We prefer you contact us direct at the factory with any problems you may be experiencing.We help diagnose the problem, arrange for any needed parts, and schedule a technician to do the repairs.Rarely can a local contractor get all that done for you as quickly as we can.We also guarantee the work .
Our Company
OTS (Overall Testing System)
Was established in 1978, with 35 years' history
With 30,000 square meter salable production base and 120 employees
Is one of the leading companies solely dedicated to manufacture of
Environmental Simulation Test Chambers ,Physical Testing Equipment .
(such as constant temperature and humidity chambers, environmental chambers, climatic test chambers, rain and dust test chambers,thermal shock test chambers,fast change rate chambers, salt spray chamber,UV test chambers,walk in test chambers and other special customized test chambers ;Tensile testing machine, vibration test machine ,carton compression testing machines, bursting strength testing machine etc.) ..
OTS has the equipment and expertise, with own R&D and consultant team, to meet and exceed your testing requirement.With offices in unrivaled quality advantage, dynamic management team with superb manufacturing process,also the quality with the world norms:ISO , ASTM, DIN, EN, GB, BS, JIS, ANSI, UL,CE, TAPPI, AATCC, IEC, VDE...
FAQ:
Q1 :Can you customize the product?
A:Yes, we can customize any products according to requirements.Hot selling lab electronic temperature humidity cabinet/Environmental climate test chamber also can be customized.
Q2 :How to choose the most suitable products?
A:Our professional team will give you the best suggestion,just be patiently to tell us the information about the parameters your required.
Q3 :Can you arrange installations and commissioning in our lab?
A:Firstly, for standard chamber we had 3-5 days commissioning before shipping , you just need link power in your lab, then can start to operate
Secondly;We had detailed operation manual with chamber , any problems you can find and solve in it
Thirdly, some of customized chambers we should to install and teach your team to operate .
If you want to know more information...
Please leave a message below and click " SEND "
Thanks for your time and attention~Thank you!
Dongguan Xin Bao Instrument Co., Ltd with owner brand of OTS has been dedicating in providing professional testing equipment with top quality since its establishment in 1978, It owns sophisticated and advanced technology in producing temperature and humidity chambers, climatic test chambers, environmental chambers, thermal shock test chambers, rain and dust test chambers, salt spray chambers, walk in /drive in test chambers and other customized test chambers, tensile testing machine, vibration test machine, Paper Packaging Testing Equipment, Luggage Testing Equipment, Furniture Testing Equipment, Leather and Shoes Testing Equipment, Mobile phone and PC Testing Equipment, Battery Testing Equipment, Plastic and Rubber Testing Equipment, Products made by OTS reach international standards: ISO, ASTM, DIN, EN, GB, BS, JIS, AMSI, UL, TAPPI, AATCC, IEC. They are also widely used in different area: R&D Institutions, Quality Inspection Institutions, Universities, electronics, communications, instrumentation, automobile, plastic, metal, Building materials, Aviation, etc.
Now our company has two main production bases over 3 0, 0 0 0m² Each in Taiwan and Dongguan, a branch company in Suzhou and offices in South Asia, Europe, USA. OTS has an independent laboratory which exhibits all of our currently produced machines, so customers can check the function and quality in one-time. What's more, OTS has many finished equipment in stock so that we can delivery products to you urgently. Every machine produced by OTS must be examined before shipment and with lifetime maintenance service.
With the exquisite manufacturing process, an innovative development and research team, a professional sales team and excellent after-sale service, OTS is ready to take part into international market and set an example in this field.
