| Prod Model: |
OH-0.31F |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Dimension: |
750*450*185 |
| Air Quantity: |
19m3/Min |
| Gas-Consumption: |
3.41nm3kg/H |
| Power Source: |
220V 50Hz |
| Control Type: |
Two Grade |
| Heating Ability: |
36000kcal/H |
| Heating Area: |
130-280 |
| Type: |
Environmentally Diesel Furnace |
| Fuel: |
Fuel |
Product Description
Detailed description:³
1.Advanced heating ability:
Because of using FE combustion mode, it won't appear hypoxia and air pollutions, heating fast,efficient, safe.
2.Nice appearance, easy operation
The application of air filter device,explosion-proof device, combustion detection equipment, overheating protection device and so on many kinds of safety device in combustion chamber top,makes operation specially safety.
3. Equipped with a variety of safety protection circuit outside:
Not only automatic operation, automatic temperature adjustment, but also optional for blower do up, down, left, right direction of adjustment, heating more prosperous.
4. The heater application scope:
apply to factory, agricultural trellis, schools, gymnasium, bath lounge, canteen, conference room, library and public places.
Technical parameter:
| | heating ability | heating house area | air quantity | dimensions | oil consumption | gas consumption | power source | control type |
| OH-1.31F | 13000kcal/h | 80-120m² | 19m³/min | 750*450*185 | 1.58kg/h | 1.55Nm³/h | 220/v50hz | two grade |
| OH-2.51F | 25000kcal/h | 100-200m² | 34m³/min | 750*450*185 | 2.97kg/h | 2.91Nm³/h | 220v/50hz | two grade |
| OH-0.31F | 36000kcal/h | 130-280m² | 40m³/min | 750*450*185 | 3.48kg/h | 3.41Nm³/h | 220v/50hz | two grade |
| OH-051F | 50000kcal/h | 240-480m² | 60m³/min | 950*540*200 | 5.58kg/h | 5.47Nm³/h | 220v/50hz | two grade |
characteristics:
1. Precision temperature control.
2.Adopt top-quality insulating materials.
3. Gas, fuel fire safety and stability, burning full.
4. Automatic operation: combustion quantity, combustion temperature control, the entire process of automatic control, safety protection.
5. Suitable for various kinds of fuel gas, liquefied gas,natural gas, diesel, kerosene, etc.
Technical support:
1: 3D video guide
2: mannual book in english
3:technical drawing
4:experienced engineers' guidance
