6s High Quality Shaking Table for Gold Mining Machine

6s High Quality Shaking Table for Gold Mining Machine
Price: US $ 1300-1600/Set
Min Order: 1/Set
Pay Type: L/C,T/T,Western Union
Prod Model: 6-S
Name: Shaking Table
Application: Mine
Capacity: 1t/H
Table Direction: Left&Right
Sorting Area: 7.5 M2
Horizontal Gradient: 0.5 Degree
Stroke: 10-30mm
Type: Gravity Separator
Voltage: 380V
Weight: <1T
Certification: ISO9001:2008
Warranty: 1 Year
Color: Black
Customized: Non-Customized
Condition: New
Material: Glass Steel

Product Description

6s High Quality Shaking Table for Gold Mining Machine


Introduction :
     Shaking table is applied in ore dressing of non-ferrous metals, ferrous metals, rare metals, such as tungsten, tin, iron, manganese, chrome, titanium, gold, niobium and bismuth, as well as different process of roughing, cleaning, and scavenging.

Working principle of shaking table:
  The working principle of Shaking Table is to use the combined action of the specific gravity difference of sorted minerals, alternating movement of bed surface, and transverse oblique water flow and riffle (or notch grooveto allow loose layering of ores on the bed surface and fan shaped zoning. Then different products can be produced.

Deck Type  Shaking Table have three distinct deck designs available.
Course ore deck  is designed for recovering particles size from 0.5 mm to 2 mm;
Fine sand deck   is designed for recovering fine particles in the range of 0.074 mm to 0.5 mm;
Slime deck  is designed for recovering super extremely fine particles in the range of 0.05 mm to 0.074mm

Technical parameter:

ModelLs<6-s>
Table structureGlass steel material, composite structure
Table specification1500-1850X4500mm
Sorting area7.5 m2
Table directionLeft and right
Horizontal gradient0.5 degree
Stroke10-30mm
Stroke frequency240-360c/min
Coarse sand 2-0.5mm;  fine sand 0.5-0.074mm;  slurry 0.074mm








Service Pre-sale support:
We can enable them to get rich and generous returns on their investments:
1.  Select equipment model;
2.  Design and manufacture products according to clients' special requirement;
3.  Train technical personnel for clients.
CITICHL Heavy Industries Co., Ltd. The former was CITIC Heavy Machinery Co., Ltd. It was used be subsidiary of CITIC heavy machinery Co., Ltd. The company was founded in 1981 and finished joint stock reform in 2005, which is located in Luoyang city, capital city of nine dynasties in ancient times.

With a garden-like industrial park and modern standard plant covering 80000 square meters, CITICHL possesses advanced equipments, technologies and detecting methods. After more than 30 years development, the company has developed into a collectivized one with product designing, manufacture, installation and technical services.

The products comprise all the equipments used in mining, ore dressing, hoisting, coal preparation, crushing and grinding, cement plant, metallurgic and steel rolling, environment protection, and also power generator, heavy-duty gear reducers and large-sized castings and forgings, etc.

CITICHL is national major industry and heavy machinery manufacturing base in the middle of China, we can supply the customers with important complete technical equipments in mining, non-ferrous metal, chemical industry, metallurgy, construction materials, environment protection, and power generating as well as other basic industries. The company can accept the packed engineering project. Our products are sold well to countries and regions in Asia, Africa, Europe, and Australia, and hold a large market share home and abroad.
