| Prod Model: |
YSA-3 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Test Basket Size: |
100*540*260mm with 3 Drawers |
| External Size: |
610*540*340mm |
| Temp. Range: |
R.T. +10 Degrees to 98 Degrees |
| Temp. Accuracy: |
+/-0.3degree |
| Temp.Resolution: |
+/-0.1degree |
| Heat Up Time: |
45 Mins |
| Insulation: |
PU&Fiberglass Wool |
| Color: |
Stainless Steel |
| Interior Chamber Material: |
SUS#304 Stainless Steel Plate |
| Exterior Chamber Material: |
Stainless Steel Plate + Powder Coated |
| Type: |
Material Testing Machine |
| Weight: |
100-500Kg |
| Power Source: |
AC220V |
| Oil Cylinder Position: |
N/a |
Product Description
3 Drawers Control Temp. Ageing Cabinet
Introduction&Application:
3 Drawers Control Temp. Ageing Cabinet simulates the environment of high temperature high humidity, which is used to detect the resistance ability of metal plating, plastic plating, metal products, metal products, electronic appliances, electronic hardware, hardware plastic, chemical coating, painting, auto accessories, auto parts, bicycle, sanitary ware, plumbing equipment, screw, fasteners, magnetic materials, locks, metal furniture, sports equipment and other industries under the extremely high temperature high moisture climate, so as to judge the reliability and stability for the products, improve the products quality and provide the basis for the reliability.
Feature:
1 Stainless steel SUS#304 made, easy setting operation.
2 Microcomputer digital LED. Control with time function.
3 Max. Setting time is 9990 Hrs.
4 Safety device.
5 Test the temperature of spare parts, connector passive component and
Semiconductor.
6 Temperature controller: Digital electronic indicators + S. S. R. With P. I. D & timer(Max. 9990 Hrs).
7 Best after sales service: One year free parts maintenance.
8 Meet international test standards.
9 Customization is available & welcomed.
Technical parameters,please see the label.
| Specification |
| MODEL | YSA-3 | YSA-4 |
| Test basket.W×H×D(mm) | 100×54×260,3Sets | 100×54×260,4Sets |
| External Dim.W×H×D(mm) | 610×540×340 | 760×540×340 |
| Ferformance | Temp.Range | R.T+10ºC-- +98ºC |
| Temp.Constancy | ±0.3ºC |
| Temp.Resolution | ±0.1ºC |
| Heat-up( min ) | 45mins |
| Material | Exterior | SUS#304 stainless steel piate |
| Interior | SUS#304 stainless steel piate |
| Insulation | PU & Fiberglass wool |
| SYSTEMS | Heating | Chrome Steel Strip Wire Heater |
| Controller | Digital electronic indicators controller+S.S.R.With P.I.D & timer max 9,990mins |
| Safety Devices | Overheating prevention pretector, |
| Water shortage protector, steam outlet hole, no fuse breaker. |
| Power Source[K.W.] | AC 1Ψ 220V 60/50Hz |
| 1.1 | 2.5 |
More details about the specification, please contact Angela Cheng, thanks for your attention.
Except 3 Drawers Control Temp. Ageing Cabinet, Dongguan Yuan Yao Electronics Technology Co., Ltd also can supply:
Precision Oven Tester, Triple Type Temp. & Humi. Chamber, Temp. &Humi. Control Host, Air Thermal Shock Tester, Liquid Thermal Shock Tester, Salt Spray Tester, Walk-in environmental Test Room, Temp. Humi. &Vibration Conbined Test Chamber, Aging Oven Tester, Rain/Spray Test Chamber, Burn-in test equipment, Dust Tester, Steam Aging Tester, Vibration Tester, Tensile Tester, Drop Tester and so on.
Welcome to enquire and purchase!
Founded in 2009, Dongguan Yuanyao Electronics Technology Co., Ltd. Has become a leading manufacturer of environmentally friendly test chambers.
Our main products include Programmable Temperature & Humidity Chambers, Thermal Shock Testers, Walk-In Environmental Test Rooms, LCM (LCD) Aging Chambers, Salt Spray Testers, Aging Ovens, Vibration Combined Test Chambers, Steam Aging Testers, etc.
We have helped companies in a wide range of industry sectors including photo electricity, electronic communication, semi-conductor, electric appliance and machine, spaceflight, automobile, locomotive, telecommunication, food and pharmacy and academic institutions realize their climate test objectives.
We have developed rapidly these years. The commitment of our experienced team of engineers has been and continued to be excellence - excellence in engineering and design, excellence in manufacture and excellence in the service that we provide for our ever increasing lists of customers.
Our resources and expertise enable us to supply high quality equipment ranging from simple benchtop chambers to major "turnkey" projects. We can produce equipment according to customers' Exact requirements, from conception to completion.
We will take an active role to ensure that our equipment proposed will not only meet the specifications but also will be made as per the budget. We also provide timely delivery.
