Price: | US $ 140-170/Square Meter |
---|---|
Trade Terms: | FOB,DDP,EXW |
Min Order: | 30/Square Meter |
Pay Type: | T/T,Western Union |
Prod Model: | 1.22m*1.22m |
---|---|
Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Size: | 1.22*1.22m,1.22*2.44m |
Faction: | Moving,Folding Stage |
Stage Topping Material: | Plexiglass,Aluminum Glass |
Usage Of Stage: | Wedding,Performance |
Frame Material: | Aluminum Alloy 6061-T6/6082-T6 |
Topping Color: | Red ,Brown,Black |
1.Aluminum Truss Series----Screw Truss | |
200mmx200mm screw truss | Main Tube:25mmx25mmx2mm / 30mm*2mm , Inclined Tube:15mmx2mm Length:0.5m-4m Large Span:10m,Large Bearing:75kg 4 sides inclined tube with 8mm thickness aluminum plate joint. |
300mmx300mm screw truss | Main Tube:50mmx3mm,Brace Tube:30mmx2mm,Inclined Tube:25mmx2mm Length:0.5m-4m,Large Span:12m,Large Bearing:350kg,2 sides inclined tube 50mmx25mmx3mm mesh word tube joint |
300mmx300mm screw truss | Main Tube:50mmx3mm,Brace Tube:50mmx2mm,Inclined Tube:25mmx2mm Length:0.5m-4m,Large Span:13m,Large Bearing:400kg,2 sides inclined tube 12mm thickness aluminum triangle plate joint |
350mmx350mm screw truss | Main Tube:50mmx3mm,Brace Tube:30mmx2mm,Inclined Tube:25mmx2mm Length:0.5m-4m,Large Span:13m,Large Bearing:375kg,2 sides inclined tube 50mmx25mmx3mm mesh word tube joint |
350mmx350mm screw truss | Main Tube:50mmx3mm,Brace Tube:50mmx2mm,Inclined Tube:25mmx2mm Length:0.5m-4m,Large Span:13m,Large Bearing:400kg 12mm thickness aluminum triangle plate joint |
400mmx400mm screw truss | Main Tube:50mmx3mm,Brace Tube:50mmx2mm,Inclined Tube:25mmx2mm Length:0.5m-4m,Large Span:14m,Large Bearing:500kg,2/4 sides inclined tube 12mm thickness aluminum triangle plate joint |
450mmx450mm screw truss | Main Tube:50mmx3mm,Brace Tube:50mmx2mm,Inclined Tube:25mmx2mm Length:0.5m-4m,Large Span:15m,Large Bearing:550kg,4 sides inclined tube 12mm thickness aluminum triangle plate joint |
400mmx600mm screw truss | Main Tube:50mmx3mm,Brace Tube:50mmx2mm,Inclined Tube:25mmx2mm Length:0.5m-4m,Large Span:13m,Large Bearing:400kg 12mm thickness aluminum triangle plate joint |
500mmx500mm screw truss | Main Tube:50mmx3mm,Brace Tube:50mmx2mm,Inclined Tube:25mmx2mm Length:0.5m-4m,Large Span:16m,Large Bearing:550kg,4 sides inclined tube 12mm thickness aluminum triangle plate joint |
500mmx600mm screw truss | Main Tube:50mmx3mm,Brace Tube:50mmx2mm,Inclined Tube:25mmx2mm Length:0.5m-4m Large Span:18m Large Bearing:600kg 2sides inclined tube 12mm thickness aluminum triangle plate |
500mmx600mm screw truss | Main Tube:50mmx4mm Brace Tube:50mmx3mm Inclined Tube:30mmx2mm Length:0.5m-4m Large Span:20m Large Bearing:800kg 2sides inclined tube 12mm thickness aluminum triangle plate joint |
520mmx760mm screw truss | Main Tube:50mmx4mm,Brace Tube:50mmx3mm,Inclined Tube:30mmx2mm Length:0.5m-4m Large Span:22m Large Bearing:1000kg 2 sides inclined tube 12mm thickness aluminum triangle plate joint |
760mmx910mm screw truss | Main Tube:50mmx4mm,Brace Tube:50mmx4mm.Inclined Tube:30mmx2mm Length:0.5m-4m,Large Span:30m,Large Bearing:1500kg,2 sides inclined tube 12mm thickness Aluminum triangle plate joint |
2.Aluminum Truss Series----Spigot Truss | |
200mmx200mm spigot truss | Main Tube:30mmx2mm,Inclined Tube:15mmx2mm,Length:0.5m-4mLarge Span:10m,Large Bearing:75kg,4 sides inclined tube with spigot joint. |
289mmx289mm spigot truss | Main Tube:50mmx3mm,Inclined Tube:25mmx2mm,Length:0.5m-4m,Large Span:12m,Large Bearing:350kg,4 sides inclined tube with spigot joint. |
389mmx389mm spigot truss | Main Tube:50mmx3mm,Brace Tube:30mmx2mm for 2 part,Inclined Tube:25mmx2mm Length:0.5m-4m,Large Span:13m,Large Bearing:450kg,4 sides inclined tube with spigot joint. |
389mmx389mm spigot truss | Main Tube:50mmx3mm,Brace Tube:50mmx2mm,Inclined Tube:25mmx2mm Length:0.5m-4m,Large Span:14m,Large Bearing:500kg,4 sides inclined tube with spigot joint. |
400mmx600mm spigot truss | Main Tube:50mmx3mm,Brace Tube:50mmx2mm,Inclined Tube:25mmx2mm Length:0.5m-4m,Large Span:16m,Large Bearing:550kg,2 sides inclined tube with spigot joint. |
450mmx450mm spigot truss | Main Tube:50mmx3mm,Brace Tube:50mmx2mm,Inclined Tube:25mmx2mm Length:0.5m-4m,Large Span:15m,Large Bearing:550kg,4 sides inclined tube with spigot joint. |
500mmx600mm spigot truss | Main Tube:50mmx3mm,Brace Tube:50mmx2mm,Inclined Tube:25mmx2mm Length:0.5m-4m,Large Span:18m,Large Bearing:600kg,2 sides inclined tube with spigot joint. |
500mmx600mm spigot truss | Main Tube:50mmx4mm,Brace Tube:50mmx3mm,Inclined Tube:30mmx2mm Length:0.5m-4m,Large Span:20m,Large Bearing:800kg,2 sides inclined tube with spigot joint. |
520mmx760mm spigot truss | Main Tube:50mmx4mm,Brace Tube:50mmx3mm,Inclined Tube:30mmx2mm Length:0.5m-4m,Large Span:22m,Large Bearing:1000kg,2 sides inclined tube with spigot joint. |
600mmx760mm spigot truss | Main Tube:50mmx4mm,Brace Tube:50mmx3mm,Inclined Tube:30mmx2mm Length:0.5m-4m,Large Span:24m,Large Bearing:1500kg,2 sides inclined tube with spigot joint. |
760mmx910mm spigot truss | Main Tube:50mmx4mm,Brace Tube:50mmx4mm,Inclined Tube:30mmx2mm Length:0.5m-4m,Large Span:24m,Large Bearing:1500kg,2 sides inclined tube with spigot joint |
