Smcj130/Smcj130A Surface Mount Transient Voltage Suppressors Peak Pulse Power 1500W

Name: Smcj130/Smcj130A Surface Mount Transient Voltage Suppressors Peak Pulse Power 1500W
Brand: thisfurniture.com
SKU: 712467932
Availability: InStock
Rating: 4.7 (117 reviews)

Price:	US $ 0.01/Piece
Min Order:	50000/Piece
Pay Type:	T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	SMCJ130/SMCJ130A
Power Dissipation:	1500
Stand Off Voltage:	130
Manufacturing Technology:	Optoelectronic Semiconductor
Material:	Element Semiconductor
Type:	N-type Semiconductor
Package:	PGA(',Pin Grid Array Package)
Model:	Smcj5.0
Batch Number:	2016
Brand:	Sy

Product Description

SMCJ5.0 thru 188CA

Surface Mount Transient Voltage Suppressors

Peak Pulse Power 1500W Stand-off Voltage 5.0 to 188V

FEATURE

Plastic package has Underwriters Laboratory Flammability Classification 94V-0

Low profile package with built-in strain relief for surface mounted applications

Glass passivated junction
Low incremental surge resistance, excellent clamping capability 1500W peak pulse power capability with a 10/1000us

waveform, repetition rate (duty cycle): 0.01% Very fast response time

High temperature soldering guaranteed:

250oC/10 seconds at terminals

Mechanical Data

Case: JEDEC DO-214AB(SMC J-Bend) molded plastic over passivated junction

Terminals: Solder plated, solderable per MIL-STD-750, Method 2026

Polarity: For unidirectional types the band denotes the cathode, which is positive with respect to the anode under normal TVS operation

Weight: 0.007oz., 0.21g

Devices for Bidirectional Applications

For bi-directional devices, use suffix CA (e.g. SMCJ10CA). Electrical characteristics apply in both directions.

Maximum Ratings and Thermal Characteristics

(Ratings at 25oC ambient temperature unless otherwise specified.)

P arameter	S ymbol	Value	Unit

Peak pulse power dissipation with	PPPM	Minimum 1500	W
a 10/1000us waveform (1) (2)	PPPM	Minimum 1500	W
Peak pulse current with a 10/1000us waveform (1)	I	See Next Table	A
	PPM
Peak forward surge current 8.3ms single half sine-wave	IFSM	200	A
uni-directional only (2)	IFSM	200	A
Typical thermal resistance, junction to ambient (3)	R	75	oC/W
	θ JA
Typical thermal resistance, junction to lead	R	15	oC/W
	θ JL
Operating junction and storage temperature range	T , T	-55 to +150	oC
	J STG

Notes: 1. Non-repetitive current pulse, per Fig.3 and derated above TA=25oC per Fig. 2

Mounted on 0.31 x 0.31" (8.0 x 8.0 mm) copper pads to each terminal

Mounted on minimum recommended pad layout

SURFACE MOUNT TRANSIENT VOLTAGE SUPPRESSOR RANGE

(SURFACE MOUNT TRANSIENT VOLTAGE SUPPRESSORS)


TYPE	Breakdown Voltage			Stand-off Voltage	Maximum Reverse Leakage @VRWM	Maximum Peak Pulse Current	Maximum Clamping Voltage@IPPM	Power Dissipation	Package


	VBR@IT		IT	VRWM	IR	IRSM	VRSM	Pd
	Min	Max	mA	V	μA	A	V	W
SMCJ5.0	6.40	7.82	10	5.0	800	156.3	9.6	1500	DO-214AB (SMC)
SMAC5.0A	6.40	7.07	10	5.0	800	163.0	9.2	1500
SMCJ6.0	6.67	8.15	10	6.0	800	131.6	11.4	1500
SMCJ6.0A	6.67	7.37	10	6.0	800	145.6	10.3	1500
SMCJ6.5	7.22	8.82	10	6.5	500	122.0	12.3	1500
SMCJ6.5A	7.22	7.98	10	6.5	500	133.9	11.2	1500
SMCJ7.0	7.78	9.51	10	7.0	200	112.8	13.3	1500
SMCJ7.0A	7.78	8.60	10	7.0	200	125.0	12.0	1500
SMCJ7.5	8.33	10.3	1.0	7.5	100	104.9	14.3	1500
SMCJ7.5A	8.33	9.21	1.0	7.5	100	116.3	12.9	1500
SMCJ8.0	8.89	10.9	1.0	8.0	50	100.0	15.0	1500
SMCJ8.0A	8.89	9.83	1.0	8.0	50	110.3	13.6	1500
SMCJ8.5	9.44	11.5	1.0	8.5	20	94.3	15.9	1500
SMCJ8.5A	9.44	10.4	1.0	8.5	20	104.3	14.4	1500
SMCJ9.0	10.0	12.2	1.0	9.0	10	88.8	16.9	1500
SMCJ9.0A	10.0	11.1	1.0	9.0	10	97.4	15.4	1500
SMCJ10	11.1	13.6	1.0	10.0	5.0	79.8	18.8	1500
SMCJ10A	11.1	12.3	1.0	10.0	5.0	88.2	17.0	1500
SMCJ11	12.2	14.9	1.0	11.0	5.0	74.6	20.1	1500
SMCJ11A	12.2	13.5	1.0	11.0	5.0	82.4	18.2	1500
SMCJ12	13.3	16.3	1.0	12.0	5.0	68.2	22.0	1500
SMCJ12A	13.3	14.7	1.0	12.0	5.0	75.4	19.9	1500
SMCJ13	14.4	17.6	1.0	13.0	5.0	63.0	23.8	1500
SMCJ13A	14.4	15.9	1.0	13.0	5.0	69.8	21.5	1500
SMCJ14	15.6	19.1	1.0	14.0	5.0	58.1	25.8	1500
SMCJ14A	15.6	17.2	1.0	14.0	5.0	64.7	23.2	1500
SMCJ15	16.7	20.4	1.0	15.0	5.0	55.8	26.9	1500
SMCJ15A	16.7	18.5	1.0	15.0	5.0	61.5	24.4	1500
SMCJ16	17.8	21.8	1.0	16.0	5.0	52.1	28.8	1500
SMCJ16A	17.8	19.7	1.0	16.0	5.0	57.7	26.0	1500
SMCJ17	18.9	23.1	1.0	17.0	5.0	49.2	30.5	1500
SMCJ17A	18.9	20.9	1.0	17.0	5.0	54.3	27.6	1500
SMCJ18	20.0	24.4	1.0	18.0	5.0	46.6	32.2	1500
SMCJ18A	20.0	22.1	1.0	18.0	5.0	51.4	29.2	1500
SMCJ20	22.2	27.1	1.0	20.0	5.0	41.9	35.5	1500
SMCJ20A	22.2	24.5	1.0	20.0	5.0	46.3	32.4	1500
SMCJ22	24.4	29.8	1.0	22.0	5.0	38.1	39.4	1500
SMCJ22A	24.4	26.9	1.0	22.0	5.0	42.3	35.5	1500
SMCJ24	26.7	32.6	1.0	24.0	5.0	34.9	43.0	1500
SMCJ24A	26.7	29.5	1.0	24.0	5.0	38.6	38.9	1500
SMCJ26	28.9	35.3	1.0	26.0	5.0	32.2	46.6	1500
SMCJ26A	28.9	31.9	1.0	26.0	5.0	35.6	42.1	1500
SMCJ28	31.1	38.0	1.0	28.0	5.0	30.0	50.1	1500
SMCJ28A	31.1	34.4	1.0	28.0	5.0	33.0	45.4	1500
SMCJ30	33.3	40.7	1.0	30.0	5.0	28.0	53.5	1500
SMCJ30A	33.3	36.8	1.0	30.0	5.0	31.0	48.4	1500
Notes:suffix with "CA" means bi-directional(e.g,SMCJ5.0CA), electrical characteristics apply in both directions.
CA ,(:SMCJ5.0CA),

(SURFACE MOUNT TRANSIENT VOLTAGE SUPPRESSORS)


TYPE	Breakdown Voltage			Stand-off Voltage	Maximum Reverse Leakage @VRWM	Maximum Peak Pulse Current	Maximum Clamping Voltage@IPPM	Power Dissipation	Package


	VBR@IT		IT	VRWM	IR	IRSM	VRSM	Pd
	Min	Max	mA	V	μA	A	V	W
SMCJ33	36.7	44.9	1.0	33.0	5.0	25.4	59.0	1500	DO-214AB (SMC)
SMCJ33A	36.7	40.6	1.0	33.0	5.0	28.1	53.3	1500
SMCJ36	40.0	48.9	1.0	36	5.0	23.3	64.3	1500
SMCJ36A	40.0	44.2	1.0	36	5.0	25.8	58.1	1500
SMCJ40	44.4	54.3	1.0	40	5.0	21.0	71.4	1500
SMCJ40A	44.4	49.1	1.0	40	5.0	23.3	64.5	1500
SMCJ43	47.8	58.4	1.0	43	5.0	19.6	76.7	1500
SMCJ43A	47.8	52.8	1.0	43	5.0	21.6	69.4	1500
SMCJ45	50.0	61.1	1.0	45	5.0	18.7	80.3	1500
SMCJ45A	50.0	55.3	1.0	45	5.0	20.6	72.7	1500
SMCJ48	53.3	65.1	1.0	48	5.0	17.5	85.5	1500
SMCJ48A	53.3	58.9	1.0	48	5.0	19.4	77.4	1500
SMCJ51	56.7	69.3	1.0	51	5.0	16.5	91.1	1500
SMCJ51A	56.7	62.7	1.0	51	5.0	18.2	82.4	1500
SMCJ54	60.0	73.3	1.0	54	5.0	15.6	93.6	1500
SMCJ54A	60.0	66.3	1.0	54	5.0	17.2	87.1	1500
SMCJ58	64.4	78.7	1.0	58	5.0	14.6	103	1500
SMCJ58A	64.4	71.2	1.0	58	5.0	16.0	96.3	1500
SMCJ60	67.7	81.5	1.0	60	5.0	14.0	107	1500
SMCJ60A	67.7	73.7	1.0	60	5.0	15.5	96.8	1500
SMCJ64	71.1	86.4	1.0	64	5.0	13.2	114	1500
SMCJ64A	71.1	78.6	1.0	64	5.0	14.6	103	1500
SMCJ70	77.8	95.1	1.0	70	5.0	12.0	125	1500
SMCJ70A	77.8	86.0	1.0	70	5.0	13.3	113	1500
SMCJ75	83.3	102.0	1.0	75	5.0	11.2	134	1500
SMCJ75A	83.3	92.1	1.0	75	5.0	12.4	121	1500
SMCJ78	86.7	106.0	1.0	78	5.0	10.8	139	1500
SMCJ78A	86.7	95.8	1.0	78	5.0	11.9	126	1500
SMCJ85	94.4	115.0	1.0	85	5.0	9.9	151	1500
SMCJ85A	94.4	104.0	1.0	85	5.0	10.9	137	1500
SMCJ90	100.0	122.0	1.0	90	5.0	9.4	160	1500
SMCJ90A	100.0	111.0	1.0	90	5.0	10.3	146	1500
SMCJ100	111.0	136.0	1.0	100	5.0	8.4	179	1500
SMCJ100A	111.0	123.0	1.0	100	5.0	9.3	162	1500
SMCJ110	122.0	149.0	1.0	110	5.0	7.7	196	1500
SMC110A	122.0	135.0	1.0	110	5.0	8.5	177	1500
SMCJ120	133.0	163.0	1.0	120	5.0	7.0	214	1500
SMCJ120A	133.0	147.0	1.0	120	5.0	7.8	193	1500
SMCJ130	144.0	176.0	1.0	130	5.0	6.5	231	1500
SMCJ130A	144.0	159.0	1.0	130	5.0	7.2	209	1500
SMCJ150	167.0	204.0	1.0	150	5.0	5.6	268	1500
SMCJ150A	167.0	185.0	1.0	150	5.0	6.2	243	1500
SMCJ160	178.0	218.0	1.0	160	5.0	5.2	287	1500
SMCJ160A	178.0	197.0	1.0	160	5.0	5.8	259	1500
SMCJ170	189.0	231.0	1.0	170	5.0	4.9	304	1500
SMCJ170A	189.0	209.0	1.0	170	5.0	5.5	275	1500
Notes:suffix with "CA" means bi-directional(e.g,SMCJ5.0CA), electrical characteristics apply in both directions.
CA ,(:SMCJ5.0CA),
