| Prod Model: |
OBH-6OB |
| Available Fuel: |
Heavy Oil, Light Oil, Natural Gas |
| Rated Oil Conbustion: |
31.4kg/H |
| Thermal Power: |
35000kcal/H |
| Function: |
Hot Water Boiler |
| Installation: |
Packaged Boiler |
| Structure: |
Water Tube |
| Media: |
Hot Water |
| Water Circulation: |
Natural Circulation |
| Drum Placement: |
Horizontal Boiler |
| Manufacturing Level: |
A |
| Burning Style: |
Chamber Combustion Boiler |
| Usage: |
Power Station |
| Fuel: |
Hot Wate |
| Pressure: |
Pressure Atomized, Micro-Positive Pressure |
Product Description
OBH box-typed hot water boiler
Detailed introduction:1.OBH - B series central hot water unit, is the double furnace water heater units with modular design concept, output power from 300,000 Kcal/h to 2.4 million Kcal/h, has the disassembling flexible,large adapting scope and so on characters.
2.Save energy and reduce pollution
3.Noise reduction, safe and reliable | Parameters | Unit | Boiler model |
| Boilerbody | rating | MW | OBH-3OB | OBH-6OB | OBH-90B | OBH-120B | OBH-180B | OBH-240B | OBH-360B |
| thermal power | 100000kcal/h | 0.35 | O.7 | 1.05 | 1.4 | 2.1 | 2.8 | 4.2 |
| Rated working pressure | MPA | 0 | 0 | 0 | 0 | 0 | 0 | 0 |
| Rated water output temp | `C | 85 | 85 | 85 | 85 | 85 | 85 | 85 |
| Rated feed-water temp | `C | 20 | 20 | 20 | 20 | 20 | 20 | 20 |
| Circulating water volume | t/h | 12 | 24 | 36 | 48 | 72 | 96 | 144 |
| Design power | % | 91 | 90.5 | 91.2 | 91.2 | 90.8 | 91 | 91 |
| Rated oil conbustion | kg/h | 31.4 | 62.8 | 95.2 | 126.5 | 188.8 | 253 | 379.7 |
| Boiler heated area:Heating area, Already heating area | m2 | 16 | 26.98 | 38 | 56.77 | 84 | 110.47 | 159.5 |
| Available fuel | Heavy oil,light oil,natural gas |
| Combustion type | Pressure atomized, Micro-positive pressure |
| Equipment weight | kg | 680 | 1250 | 2100 | 2500 | 4500 | 5350 | 6800 |
