Ai Si Li (China) Test Equipment Co., Ltd. >> Programmable High Low Temperature (humidity) Test Chamber, /Environmental Chamber

Programmable High Low Temperature (humidity) Test Chamber, /Environmental Chamber

Programmable High Low Temperature (humidity) Test Chamber, /Environmental Chamber
Price: US $ 5000-12000/Set
Trade Terms: FOB,CIF,EXW
Min Order: 1/Set
Pay Type: L/C,T/T,D/P,Western Union,Paypal
Prod Model: TH SERIES
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Products Name: Moisture Test Chamber
Usage: Temperature & Humidity Testing
Material: SUS 304# Stainless Steel and See Cold-Rolled Steel
Humidity Range: 20%R.H.(Humidity Can Be Customized)
Temperature /Humidity: -40 Degree, 20%~98%R.H.
Compressor: French Tecumseh Brand, Germany Bizer Brand
Power: AC220V 1pH 3 Lines, 50/60Hz, AC380V 3pH 5 Li
Warranty: One Year Warranty, Lifelong Time Maintainance
Service: OEM Service, Design Service
Package: Standard Export Wooden Case
Analysis Method: Physical Analysis
Type: Temperature and Humidity Test Chamber
Application: Instrument, Automobile, Plastic, Metal, Food, Chem
Portable: Customized
Physical Analysis Type: Temperature and Humidity Test Chamber

Product Description

Programmable High Low Temperature (humidity) Test Chamber,/environmental chamber

1.Professional Manufacturer
2.Material:SUS#304
3.Customized Size
4, LCD touch screen


Programmable High Low Temperature (humidity) Test Chamber,/environmental chamber application:

Climatic chamber is used to test various types of materials for their tolerances of heat, cold, dry, humidity. It is applied for quality inspection for all types of
electronic products, electric appliance, and products from communication, instrument, automobile, plastic, metal, food, chemical, building materials,
medical and aerospace industries.




Programmable High Low Temperature (humidity) Test Chamber,/environmental chamberr feature:

1. Graceful appearance, circularly shaped body, surface treated with mist strips and plane handle with no reaction. Easy to operate, safe and reliable.

2. Rectangular doubleglassed watching window for the observation of the test
 production during the testing process. The window is
equipped with sweatproof
electrical heating device that can prevent water steam from condensing into
droplets, and with high brightness PL fluorescent
bulbs to provide light inside the box.
3. Double- layer insulated airtight doors, able to insulate the internal temperature
 effectively.


4. Water supply system that is externally connectable, convenient for refilling water into the humidifying pot and automatically recyclable.

5. The French Tecumseh brand is used for the circulation system of the compressor, capable of removing the lubricant between the condensation pipes and capillaries. The environment  protecting coolant is used for the whole series (R232,R404)

6. Imported LCD display screen, capable of displaying the measured value as well as the set value and time.

7. The control unit has the functions of multiples segment program editing, and of quick or slope control of temperature and humidity.

8. Inserted mobile pulley, convenient for movement an relocation, with strong positioning screws.


Asli Main Products:

 Environmental chamberstemperature (humidity) chamberPCT /Hast chamber (Highly accelerated stress test chamber),ESS chamberWalk in stability chamber,Vacuum oven,Altitude chamber,vibration test systemmechanical shock tester,environmental combined vibration chamber,etc








Model TH-225-D
Internal Dimension W600xH750xD500(mm)
Internal Dimension W1200xH1900xD1150(mm)
Temperature Range Low Temperature: D:-40ºC (Temperature according to customer's requirement)
Humidity Range 30%R.H.(Humidity according to customer's requirement)
 Analytic Accuracy/ Distribution uniformity of temperature and humidity 0.1ºC; 0.1% R.H/±2.0ºC; ±3.0% R.H.
Control Accuracy of Temperature and Humidity ±0.5ºC; ±2.5% R.H.
Temperature Rising/ falling Speed Rate Temperature rising approx.  0.1~3.0ºC/min / temperature falling approx.   0.1~1.5ºC/min; ( The Falling Speed Rate Min.1.5ºCper minute
 is a special optional condition)
Temperature /humidity -40 degree, 20%~98%R.H.
Material Material of the inner box is SUS 304# stainless steel, of the outer box is stainless  steel or SEE cold-rolled steel with paint coated, Insulation material is resistant to high  temperature, high density, formate chlorine,
ethyl acetum foam insulation materials
 Cooling System Wind cooling or water cooling/single segment compressor
(-40ºC, double segment compressor -70ºC)
 Protection Devices Fuse-free switch, overloading protection switch  for compressor, high and low  voltage coolant protection switch, over-humidity and over-temperature protection  switch, fuses, fault warning system, water short storage warning protection
 Optional Accessories   Inner door with operation hole , Recorder, Water Purifier, Dehumidifier
 Compressor French Tecumseh Brand,Germany Bizer Brand
 Power AC220V  1ph 3 lines, 50/60HZ ,  AC380V   3ph  5 lines , 50/60HZ
 Approx. Weight (Kg) 250
Established in 1988, ASLi (China) Test Equipment Co., Ltd is specialized in manufacturing a variety of quality inspection instruments, testing equipments and other high-tech products which mainly include: Programmable constant Temperature & Humidity Test Chamber, High & Low Temperature Test Chamber, High & low Temperature Testers with Rapid Temperature Change, Walk-In humidity & temperature test chamber, Cool/Thermal shock test chamber, Salt spray chamber, aging tester, drying oven, xenon lights resistant to climate testing machine, UV resistant to climate testing machine, ozone aging test machine, sand and dust testing machine, tension tester, high and low temperature testing machine, servo carton compression tester, mechanical vibration tester and other quality testing instruments. Thanks to several decades of R&D efforts, the company has established itself as a leading provider of testing instruments of the industry, playing a crucial role in the research and development of high-quality and high-value products within the industry.

ASLi (China) Test Equipment Co., Ltd is authenticated by competent testing centers, including the National Measurement andTestingCenterand South China Center of Metrology. Famous for precision and reliability, these products have been extensively used within the industry, by research institutions, quality inspection agencies, and colleges and universities both at home and abroad, serving a worldwide customer base.

With unmatched quality advantage, a dynamic management team, professional customer services, superb manufacturing techniques and innovative research and development ideas, ASLi (China) Test Equipment Co., Ltd, supported by an international, standard and professional quality policy, is gradually becoming an international brand. Its products are manufactured in consistent with a number of world standards, IE, ISO, ASMT, DIN, EN, GB, BS, JIS, ANSI, UL, TAPPI, AATCC, IEC, VDE, CSA and CEN.
