| Prod Model: |
JH-WF048 |
| Hinge: |
304 Stainless Steel Hydraulic Hinge |
| Drawer Slide: |
Dtc 3-Joints Drawer Slide Without Noise |
| Worktop: |
Epoxy Resin/Lab Grade Phenolic Resin/Ceramic/S.S |
| C-Frame: |
60X40X1.5(2.0) Galvanized Steel Pipe Coated |
| Reagent Shelf: |
Steel and Tempered Glass |
| Socket: |
Multi-Functional International Socket |
Product Description
Specification for lab furniture:
Product name: C-frame lab furniture(central bench)
Type: JH-WF048
The size can be custom-made requested by customers.
A. Metal frame:
1. Material for upright frame: It's made of 60X40X1.5(2.0)mm galvanized steel pipe by welding, it's with epoxy resin powder after acid-washing and phosphorization.
2. Connection wing: solid plastic parts or welded steel part on C-frame itself, it depends on customer's requirement.
3. Adjustable feet: Using M10 screws(treated by galvanization) with adjustable height not less than 10mm.
B. Worktop:
Phenolic resin worktop/epoxy resin worktop/ceramic worktop/S.S which are resistant for chemicals and high temperature. The worktop can be washed easily. The worktop can bear the weight about 200-300kg. The gas height between worktop<2mm.C. cabinet:
1. It's made of E1 standard 18mm chipboard, MDF with melamine or plywood with 2mm PVC water proof edgings.
2. The back panel can be dissembled and it's convenient for installation and maintain of pipe and electricity cable.
3. Drawer sliding rail: Using steel 3-joints weight bearing sliding rail without noise on both sides of drawer.
4. Handle: Using stainless U-type specialized handle in lab or long aluminu alloy grab handle.5. Hinge: 304 stainless stee hydraulic hinge which is rust resistance.
Worktop description:
| Lab-grade phenolic resin worktop. | Epoxy resin workstop | Ceramic workstop |
Ingredient | Dipping phenolic resin into special multi-layer kraft paper , it is hot-solid formed under high temperature and pressure. | Quartz sand and epoxy mixed with special bond | Combined clay,kaolin and feldspar mixed with many special material |
Corrosive resistance | It is resistant for many kinds of acid,alkali,solvent and reagent etc. | It is resistant for many kinds of acid,alkali,solvent and reagent etc | Excellent |
Heat resistance | Normal: 135ºC, it could not touch flame directly. | 600ºC heat resistance | 1000ºC heat resistance |
Colour | Black,gray,dark green | Gray,gray,green | Black,gray,white,green |
Worktop thickness | 12.7mm,16mm,19mm | 16mm,19mm,25mm | 20mm |
| Water resistance | water absorption:0.6% | water absorption:0.008% | Excellent |
Physics feature | Good | Good | Excellent |
