Qingdao Xinguangzheng Bere Steel Structure Co., Ltd. >> Mobile Modular 20ft Flat Pack Container House

Mobile Modular 20ft Flat Pack Container House

Mobile Modular 20ft Flat Pack Container House
Price: US $ 80/Square Meter
Trade Terms: FOB,CFR,EXW
Min Order: 200/Square Meter
Pay Type: L/C,T/T,D/P,Western Union,Paypal
Prod Model: Container house-1
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Structure Type: Portal, Truss, Grid Structure
Design Load: Wind Speed, Snow Load, Earthquake etc
Steel Grade: Q235B Q345b
Strucuture Anti Rust Grade: St2.5 Painted, or Hot DIP Galvanized
Roof And Wall: Steel Sheetsandwich, EPS Cement Panel
Bracing: Rod Steel, Angle Steel, C/Z Purlin etc.
Connection: Bolt Connect, Weld Connect
Window: Aluminum /PVC, as Requested
Door: Aluminum /PVC, as Requested
Installation: Engineer Guide Install or Send Installation Team
Material: Steel Structure
Usage: Workshop
Certification: BV
Customized: Customized

Product Description

International Horticultural Exposition resterant

Usage:

Our modular building system can be used for home, office, motel, hotel, apartment, classroom, office, meeting room, dormitory, shop, exhibition center, outdoor building. In the fields of building; Oil& Gas camp, mining camp, railway, highway, water conservancy project, electric power, business, tourism and military use.



Insulation

1)Rock wool

Density: 120kg/m3 U=0.25 W/m² K)

flammability class A - non combustible

smoke density class Q1 - low smoke emission,

certificated: CE & GL

Temperature adjustment -50c and 120c. K=0.044W/m.k

2)PU

Density: 40kg/m3 U= 0.044W/m2.k K=0.019w/m.k

Flammability class B1 - non-combustible

Smoke density - low smoke emission

Door

Steel door: single door 870x2000mm or double door 1500x2000mm

Alu door: single door 870x2040mm or double doors 1500*2040mm

Glass doors can be customized

windows

Glass: Double glass, Low-E double glazed

Frame: PVC profile or Alu profile

Type: Kinds of turn &tilt windows, sliding windows etc

Accepted customized



Floor

Ground floor will be the concrete foundation with Ceramic tiles or PVC floor leather.
First floor: 18mm plywood with 2.0mm PVC floor leather for living rooms floor

Ceiling
6mm Gypsum board for dry room
12mm PVC ceiling for wet room

Walls
Insulated Steel Sandwich Panel wall
Panel width: 950mm;
Thickness: 50-1200mm.
Powder coated Color steel on both sides: 0.4mm/0.5mm/0.6mm
Insulation: Polystyrene, Rockwool or Polyurethane
Density of Rockwool: 120Kg/m3
Density of Polystyrene: 12Kg/m3, 16KG/M3 20KG/M3
Density of Polyurethane: 40Kg/m3

Electrical fittings option
Electrical wire, 2.5mm2 for lighting system, and 4mm2 for AC units.
16A five hole universal socket.
Double tube fluorescent lamp, 220V, 50-60Hz
Single Switch, Honyar brand, with junction box
Electrical distribution box, box+breakers+earth leakage protective device

Optional Water system fittings
(1). Water drain pipe, PPR pipe, dim 16-20mm, connection fittings are made of copper, life span over 10 years.
Exhaust fan or air exchange hole, size 250mm*250mm made of steel or PVC
(2). Sanitary ware:
Western Close tool: Ceramic, with pipes and installation fittings
Urinal: Ceramic, with pipes and installation fittings
Wash basin: Ceramic, with post, faucet, pipes and installation fittings
Shower head, Shower base, Water mixture

Temporary building Characteristics:
(1). Environment protective, no garbage caused
(2). Doors, windows and interior partitions can be flexibly fixed
(3). Beautiful appearance, different colors for the wall and roof.
(4). Cost saving and transportation convenient
(5). Anti-rust and normally more than 15 years using life
(6). Safe and stable, can stand 8 grade earthquake.

Qingdao Xinguangzheng steel structure Co. Ltd specialized in various of steel structure building, jointly design, manufacture, export and erection of Industrial, Commercial and residential and Agriculture uses. We exported to more than 30 countries on 6 continents with well-established experience for more than 20 years.


Basic info
Established time  :since 1996
Factorys occupied floor area:40000 Square meter
Engineer:  more than 70 persons(keep enlarging) with 4 installaltion team
Capcity:More than 3000 tons per month
Products scopeworkshop,warehouse,prefabricated house, container house, poultry house,aircraft hanger
 with full system design, manufacture, deliver, installation and after sale service.




ItemSortNameSpecification and parameter
1product modelstandard intensitystandard product, the dimension can be designed by the customers' requirement
2removable performancethe house are divided into components in transportation and builded into a whole hoisted house
3specificationlength6058mm and 12058mm
4width2438mm
5height2591mm
6clear height indoor2400mm
7standard componentground beam3mm galvanized
8roof beam3mm galvanized
9central column4mm galvanized
10column on the corner4mm galvanized
11wall panel75mm double-faced coloured steel   EPS sandwich board
12roof panel75mm double-faced coloured steel PU sandwich board
13secondary beamZ-shaped galvanized steel iron
14roof insulation75mm polyurethane
15Floor panel18mm plywood panel+12mm  laminated floor  or 20mm cement-fiber +2mm PVC
16doorSteel Security door, 740mmx1950mm
17windowPVC Sliding window with Rolling shutter, 1100mmx800mm
18electronics, water supply and drainagethe plan, design and construction can be provided according to the related law of the country
19furniture and applianceCustomized-made
20designing parameterroof load0.5KN/sqm(If the criteria were exceeded, it can also load by reinforcing the structure)
21wind pressure load parameterdesigning wind speed   210km/h (Chinese standard)
22seismic fortification intensitymagnitudes 8
23suitable temperaturesuitable temperature scope. -50° C~+50° C
24constructionconstruction toolsconvenient construction, the tools are spanner, bolt driver and so on
25construction efficiency4 experienced technicians can build 6-8 prefab houses with dimension of 20 feet
26transportationcontainer trunkcontainer with 12 meters can load 8 houses with the dimension of 20 feet

Since 1996, Qingdao Xinguangzheng Bere Steel Structure Co., Ltd. Has been specialized in designing and manufacturing steel structure workshop, steel structure warehouse, steel structure aircraft hangar, steel structure building, steel structure poultry house and prefab houses. We also passed approval of CE, BV, SGS and ISO9001 Certification. We can send our engineer to the project site overseas. Besides, We also have our own abroad guiding installation team consisting of more than 30 people. Our steel structure buildings products have been exported to Ethiopia, Tanzania, Nigeria, South Africa, Algeria, Dubai, Saudi Arabia, Thailand, Australia, France, Germany etc. Around the world.

Production Capacity

Highly precise equipment including gantry planers, automatic submergde arc welding equipment, assembling machines, slitting machines, and shot blasting machines. We have three EPS sandwich panel production line, an annual output of 300, 000 meters; Eight corrugated steel sheet production line, an annual output of 1.225 million meters; Three production line for H section steel with an annual output of 50, 000 tons; C section steel production line six, an annual output of 4, 000 tons; A Z section steel production line an annual output of 3, 000 tons. In this way, the whole system from steel structure design, manufacture, installation to after-service was established.

R&D Capacity and Quality Control

The design team at Xinguangzheng is comprised of ten professional design engineers with master's or bachelor degrees, in addition to twenty detail designers. They are able to ensure and improve our product quality through technological innovation and strict management. They use software: Auto CAD, PKPM, 3D3S, Tekla Structures(Xsteel)V12.0. etc. Our 21 QC inspectors with up to 30 years experience rigorously tracking each step of production to ensure high qualified steel structure building, steel structure workshop, steel structure warehouse, aircraft hangar and poultry house to reach our customers.

Honor & Certification

With the business principal of "credibility determines brand", we have got lots of honors: National Class-B Certificate of Professional Contracting of Steel Structure Projects; Top 10 Corporations for Professional Contracting of Building Construction in Qingdao City; Key Enterprises in Pingdu City; Trustworthy Enterprises in Shandong Province and so on. We have passed the approval of ISO: 9001: 2008, BV, SGS Certification, also we have got the qualification certification of construction enterprise: Class I Speciality Contractor for steel structure project.

Why choose us

We have rich experiences on steel structure workshop plant warehouse construction, equipments supply and installation, construction and installation of steel structure for 18 years. With high professional technical forces and completely related supporting facilities, concentrating on customers'satisfaction, we provide our customers with full sets of equipment scheme project to creat steel structure integration project.

With comprehensive advantages of light weight, industrialized manufacture, fast installation, shorter construction time, good performance of anti-quake design, fast investment recovery period, environment friendly, the steel structure has been reasonably and widely used in construction area all over the world, especially in the developed countries and regions. Our steel structure workshop, steel warehouse building, steel structure poultry house, aircraft hangar and prefab house have been exported to more than 60 countries, such as Ethiopia, Tanzania, Nigeria, South Africa, Algeria, Dubai, Saudi Arabia, Thailand, Australia, France, Germany etc. Around the world. Provided with professional equipments, skillful consulting team and completely construction scheme on steel structure integration project, you are welcomed to visit us.
