Price: | US $ 1000-60000/Piece |
---|---|
Min Order: | 1/Piece |
Pay Type: | L/C,T/T,Western Union |
Prod Model: | SCT |
---|---|
Cooling Method: | Counter Flow |
Material: | FRP |
Certification: | CTI |
Condition: | New |
Main material | ||
Parts Name | Material | Remark |
Shell | FRP | High quality glass fiber mat Resin synthesis |
water basin | ||
sprinkler water basin | ||
tank | ||
Nozzle | ABS | |
fan | Aluminum Alloy,Aerofoil type of fan | |
motor | Totally enclosed water proof | Baiguan Brand |
filling | P.V.C | Flame-retarded |
Frame & Motor Holder | Hot Dip Galvanized Steel |
Model | Nomal flow | Overall Dimension | Motor | Fan Diam. | Water pressure | Weight(kg) | Piping Dimension(mm) | |||||
m3/h | mm | kw | mm | Kpa | N.W | Run weight | Inlet | outlet | Over | Drain | Makeup | |
SCT-10L/SA | 10 | L1000*W1400*H2270 | 0.18 | 600 | 18 | 170 | 345 | 50 | 50 | 25 | 25 | 15 |
SCT-15L/SA | 15 | L1200*W1400*H2270 | 0.37 | 770 | 19 | 195 | 395 | 50 | 50 | 25 | 25 | 15 |
SCT-20L/SA | 20 | L1200*W1400*H2370 | 0.55 | 770 | 20 | 215 | 415 | 50 | 50 | 25 | 25 | 15 |
SCT-25L/SA | 25 | L1400*W1600*H2420 | 0.60 | 770 | 21 | 255 | 490 | 80 | 80 | 25 | 25 | 15 |
SCT-30L/SA | 30 | L1400*W1600*H2570 | 1.10 | 890 | 21 | 290 | 560 | 80 | 80 | 25 | 25 | 15 |
SCT-40L/SA | 40 | L1600*W1600*H2570 | 1.10 | 890 | 22 | 315 | 600 | 80 | 80 | 25 | 25 | 15 |
SCT-50L/SA | 50 | L1600*W1600*H3750 | 1.10 | 1200 | 35 | 700 | 1300 | 100 | 100 | 50 | 50 | 25 |
SCT-60L/SA | 60 | L1800*W1800*H3750 | 1.50 | 1350 | 38 | 750 | 1400 | 100 | 100 | 50 | 50 | 25 |
SCT-70L/SA | 70 | L1900*W1900*H3750 | 1.50 | 1350 | 39 | 800 | 1500 | 100 | 100 | 50 | 50 | 25 |
SCT-80L/SA | 80 | L2000*W2000*H4200 | 4.00 | 1450 | 40 | 950 | 1950 | 125 | 125 | 50 | 50 | 25 |
SCT-90L/SA | 90 | L2100*W2100*H4200 | 4.00 | 1450 | 42 | 1000 | 2050 | 125 | 125 | 50 | 50 | 25 |
SCT-100L/SA | 100 | L2250*W2250*H4200 | 4.00 | 1800 | 45 | 1050 | 2100 | 150 | 150 | 50 | 50 | 25 |
SCT-125L/SA | 125 | L2500*W2500*H4200 | 5.50 | 2120 | 45 | 1250 | 2320 | 150 | 150 | 50 | 50 | 25 |
SCT-150L/SA | 150 | L2750*W2750*H4200 | 5.50 | 2120 | 45 | 1420 | 2770 | 150 | 150 | 50 | 50 | 25 |
SCT-175L/SA | 175 | L3000*W3000*H4200 | 7.50 | 2400 | 46 | 1600 | 3250 | 200 | 200 | 80 | 80 | 40 |
SCT-200L/SA | 200 | L3250*W3250*H4200 | 7.50 | 2400 | 46 | 1750 | 3400 | 200 | 200 | 80 | 80 | 40 |
SCT-225L/SA | 225 | L3400*W3400*H4200 | 7.50 | 2600 | 46 | 1900 | 3690 | 200 | 200 | 80 | 80 | 40 |
SCT-250L/SA | 250 | L3500*W3500*H4400 | 11.00 | 2850 | 46 | 2150 | 4250 | 200 | 200 | 80 | 80 | 40 |
SCT-300L/SA | 300 | L4000*W4000*H4900 | 11.00 | 3200 | 49 | 2620 | 5100 | 250 | 250 | 80 | 80 | 40 |
SCT-350L/SA | 350 | L4250*W4250*H4900 | 11.00 | 3200 | 50 | 2950 | 5750 | 250 | 250 | 80 | 80 | 40 |
SCT-400L/SA | 400 | L5000*W5000*H5100 | 15.00 | 3400 | 52 | 3520 | 7050 | 250 | 250 | 80 | 80 | 40 |
SCT-450L/SA | 450 | L5100*W5100*H5100 | 15.00 | 3700 | 52 | 3820 | 7750 | 250 | 250 | 80 | 80 | 40 |
SCT-500L/SA | 500 | L5250*W5250*H5100 | 15.00 | 3700 | 54 | 4150 | 8100 | 300 | 300 | 100 | 100 | 50 |
SCT-600L/SA | 600 | L5500*W5500*H5300 | 18.50 | 4050 | 54 | 4680 | 8890 | 300 | 300 | 100 | 100 | 50 |
SCT-700L/SA | 700 | L6000*W6000*H5500 | 22.00 | 4250 | 56 | 5460 | 10650 | 350 | 350 | 100 | 100 | 50 |
SCT-800L/SA | 800 | L6500*W6500*H5500 | 22.00 | 4250 | 56 | 6520 | 12710 | 350 | 350 | 100 | 100 | 50 |
SCT-900L/SA | 900 | L7000*W7000*H5600 | 30.00 | 4550 | 58 | 7550 | 14720 | 400 | 400 | 100 | 100 | 80 |
SCT-1000L/SA | 1000 | L7500*W7500*H5600 | 30.00 | 4550 | 58 | 8200 | 15990 | 400 | 400 | 100 | 100 | 80 |
design condition | water inlet Temp. | 37ºC | Remark: 1.Cooling tower can be made-to-measure according to customer's design conditions and special requirement. 2. "s" means one fan | |||||||||
water outlet Temp. | 32ºC | |||||||||||
Wet Bulb Temp. | 28ºC |
