Price: | US $ 47-50/Roll |
---|---|
Min Order: | 30/Roll |
Pay Type: | L/C,T/T,Western Union,Money Gram |
Prod Model: | Flexible Plastic Table Cover |
---|---|
Color: | Natural, Light Blue or as Required |
Name: | PVC Sheet |
Character: | Super Clear, Smooth |
Thickness: | 0.05-8mm |
Width: | 100-1850mm |
Kind: | PVC Plastic Sheet |
Water Absorption: | 0.1%~0.3% |
Contraction Percentage: | 0.4%~1.4% |
Bubble: | No |
Open Styles: | Swing |
Material: | PVC |
Featured product | Popular Size | |
Super Clear Flexible PVC Sheet Welding Flexible PVC Sheet Anti-Insect Flexible PVC Sheet Gery/Black/Yellow/Red/Green Flexible PVC Sheet | Thickness: 0.1mm to 10mm Width:500mm to 2000mm Length: 20M | |
Specifications of Soft PVC Sheet | ||||
Roll Sizes | ||||
Thickness | 0.5mm to 8.0mm | |||
Width | 100mm to 1850mm | |||
Length | 10m to 100m | |||
Material Description | ||||
Finish | Smooth | |||
Colors | Clear / Blue | |||
Physical Properties | ||||
Property | ASTM | Unit | Result | |
Light transmittance | ASTM D1003 | % | 85 | |
Shore A hardness | EN ISO868 | Sh A | 80 | |
Tearing resistance | DIN 53515 | N/mm | 50 | |
Tensile stength at break | ASTM D 638 EN ISO 527 | N/mm² | 16 | |
Elongation at break | % | 340 | ||
Residual elong(after break) | % | 68 | ||
Thermal conductivity | ASTM C177 | W/m.k | 0.16 | |
Cold bend brittle temp | ISO 8570 | ºC | -35 | |
Min. usage temp | EN 1876 | ºC | -20 | |
Max. usage temp | EN ISO 306 | ºC | 50 | |
Vicat softening temp | ºC | 50 | ||
Specific heat capacity | ISO 11357 | kj/kg.k | 1.6 | |
Sound reduction | DIN52210 | Db | >35 | |
Fire retardance | NF P 92-507 AS/NZS3837 DIN 4102 | classe | Grp4 B2 | |
UV/IRfilter | AWS | Filter | ||
UV resistance | ISO 4892 | yes | ||
Charface buildup | IEC 61087 | Sparks | yes | |
Surface resistivity | IEC60093 | 1012 Ω/ | 40 | |
Water absorption | EN ISO 62 | % | .0.2 | |
Anti-insect | yes | |||
Density | ASTM D 792 | g/m3 | 1.25 |
