| Prod Model: |
BIC5028A |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| OEM: |
Available |
| Kidney Bridge Up: |
120mm |
| Certificates: |
ISO, Ce |
| Factory Location: |
1.5 Hours From Shanghai |
| Reset Function: |
Yes |
| Castor: |
4 Pieces/6 Inch |
| Size: |
2330*1050*530-710mm |
| Type Of Hospital Bed: |
Electric Bed |
| Folded: |
Unfolded |
| Using Ambient: |
Hospital |
| Numbers Of Function: |
Five-function |
| Certification: |
ISO13485 |
Product Description
BIC5028A medical ICU surgical bed with reset function
General Description:
This type of ICU bed consists of Cold-rolled steel plate and four pcs of long PP siderails.
It is mainly used in ICU room. The most advantage is the embedded controller on the foot board and both two sides of the siderails, which allow caregivers to spend their time helping patients recover quickly in a secure and comforting environment.
Feature:
- Made of superior cold-rolled steel
- Bed Surface: back section and leg section by ABS plastic,, middle two section made of cold rolled steel connected by abs soft connection, when bed bending, more smooth, giving patient comfortable feeling.
- Treated by shot blasting, electrophoresis and powder coating
- Four pieces of PPsplint side rails, full protection with zero gap, tuck-away
- Nurse controls on footboard and siderails
- Fixed patient controls on siderails
-Electronic function lockout controls on footboard
-- Four independent motors, standard: LINAK brand
- built-in bumpers on 4 corner of headboard and footboard
- battery back up
-reset function, ICU bed can return back to "zero" position when bed in any position
-electric central brake system via the control panel on footend and siderails
-auto contour feature simultaneously raises both the head and the knees
- Wire hidden
-CPR function(BIC5028C, BIC5028A without)
Standard Specifications
| Model number | BIC5028A BIC5028C(with CPR) |
| | |
| Measurement | Overall size(L*W*H): 2330*1050*530-710mm (with 6 inch diameter castor)
Patient Touching surface: 1955*900mm |
| Weight Load | Fully tested sturdy construction capable of taking a maximum user weight of up to
250kg |
| Function | Backrest max upward angle: 65° |
| Footrest max upward angle: 43° |
| Height: 530-710mm (castor diameter: 6 inch) |
| Trend/Reverse Trend.±10° |
| Power | 220VAC or 110VAC Frequency: 50-60HZ
Power Plug: EU type standard if other type, confirm each order |
| Package | 2080*1060*610mm, Net weight: 148kgs |
Standard Accessories List
| Headboard/Footboard | 1 set |
| Siderails | 4 pcs |
| I.V pole | 1 piece |
| Castor | 4 pieces/6 inch |
| Drainage Hook | 2 pieces |
| Motor | 4 pcs |
Optional:
1. Over Bed table
2. beside locker
3. Mattress(sponge mattress, or Bedsore prevention mattress )
