Prod Model: |
AR8 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Material: |
Steel |
Structure: |
Rack |
Type: |
Resistance Box, Meter Box |
Product Description
Packaging & Delivery
Packaging Detail: Carton, wood pallets, 40HQ container or 20GP container...
Delivery Detail: In 30days after confirmed the order(depend on your quantity...)
Specifications
1. IP55
2. Material: Cold steel rolling sheet
3. Impact resistance IK10
4. Color: RAL7032 or RAL7035
5. Single door or double door
Product Description
Material: Cold steel rolling sheet
Protection ratings: IP55
Impact resistance IK10
Color: RAL7032 or RAL7035
Paint finish expoxy polyester powder coating textured finish.
Thickness of the sheet steel: Front door: 2.0mm/rear panel: 1.5mm/enclosure body: 1.5mm/top cover & bottom cable plate: 1.5mm/galvanised mounting plate: 2.5mm
Supply include:
AR8 structur enclosure body, door complete with MS821 locking system and hinges, rear panel, top cover, bottom with removable cable entry, 4 lifting eyebolts.
|
W H D(mm) |
Model |
NO. OF DOOR |
|
1 |
1000X1000X300 |
AR8 1010/3D |
2 |
|
2 |
800X1200X300 |
AR8 128/3 |
1 |
|
3 |
1000X1200X300 |
AR8 1210/3D |
2 |
|
4 |
1200X1200X400 |
AR8 1212/4D |
2 |
|
5 |
600X1400X300 |
AR8 146/3 |
1 |
|
6 |
600X1400X400 |
AR8 146/4 |
1 |
|
7 |
800X1400X300 |
AR8 148/3 |
1 |
|
8 |
800X1400X400 |
AR8 148/4 |
1 |
|
9 |
1000X1400X400 |
AR8 1410/4D |
2 |
|
10 |
1200X1400X400 |
AR8 1412/4D |
2 |
|
11 |
600X1600X300 |
AR8 166/3 |
1 |
|
12 |
600X1600X300 |
AR8 166/3 |
1 |
|
13 |
600X1600X400 |
AR8 166/4 |
1 |
|
14 |
800X1600X300 |
AR8 168/3 |
1 |
|
15 |
800X1600X400 |
AR8 168/4 |
1 |
|
Zhejiang tianqi electric Co., Ltd., with 10 years experience in electrical industry, is one of the leading manufacturer of distribution boxes and panel meters in China. Founded in China 1998, located in the beautiful land scape of the largest China bamboo sea in anji economic development zone which place is in the north of zhejiang, covers an area of 100, 000 square meters and has 500 employees.
T&j's product range consists of wall mounting enclosures, floor standing cabinets, stainless steel enclosures, plastic enclosures, terminal boxes, power distribution cabinets, floor standing modular cabinets, console systems, analog panel meters, digital panel meter, DIN rail panel meter, current transformer, shunt.
We also got the quality system certificate of CE, rosh, IP65 and ISO 9002 for our products. It has established the good commercial relations with America, west-europeam, east-Asia, Africa etc.
All kinds of electronics products and its accessories will be designed and manufactured according to the customer' s special requirement.
Sticking to the policy as "no quality, no future!
