| Prod Model: |
HB-DJ801 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Task: |
Adjust |
| Structure: |
Combination |
| Signal: |
Continuous |
| Mathematical Model: |
Linear |
| Features: |
Low Noise |
| Input Voltage: |
12/24VDC |
| Load Capacity: |
1400lbs |
| Speed: |
0.3~1inch Per Second |
| Stroke: |
1~24inch(Optional) |
| Min Installation Dimension: |
L=7inch+S |
| Style: |
Modern |
| Material: |
Metal |
| Wood Style: |
Panel |
| Folded: |
Unfolded |
Product Description
Product Description
HB-DJ801 is a comfortable and ergonomically correct Linear Actuator. It can provide perfect control and reliable performance. This Linear Actuator has a wide variety of functions to lift, push, tilt or adjust safely, smoothly and accurately. What's more, it only needs lower costs, easier installation and easy integration with control systems compared to other solutions. Last but not least, this efficient product focuses on safety and ergonomic working postures with long lifetime, no risk of harmful oil leaks and low energy consumption.
Feature
1) DC permanent magnet motor, compact and handy
2) Speed from 4mm/s to 25mm/s
3) Stroke: 25~600mm(optional)
4) Max Load 6000N
5) Temperature Range: -26~+65 centigrade
6)Duty cycle: 10%with full load in normal temperature
7)Reed switch output signal
8) Low Noise
9) IP Grade: 43
10) Built-in limit switches
11) Certificate: CE
12) Widely used in Medical treatment, Furniture, Industry
Our Advantages
-Customized design
-Drawing reference
-Technology support
-Oversea agent
-Fast delivery
-Perfect warranty
-Competitive Wholesale Prices
Packaging and Delivery
Packaging details: 4 or 8 PCS/CTN
Delivery detains: 10-14 days after payment
Transportation
1. All available shipping ways could be applied, by courier, air or sea. Fast Delivery, Shipping direct from China to major destinations (Europe, US, Australia, etc. ) typically takes only 5-to-10 day via DHL/TNT/UPS/FedEx/EMS, or container by Sea.
2. Appointed shipping company or our own forwarders both could be used in shipment.
3. Full-way tracking the cargos for you before the goods arrive.
Sample Availability & Policy
We can offer one or more than one samples to the buyer. The cost and freight charges should be paid by the customer. Delivery time will take 7-10 business days.
About us
HB is an expert in electric linear actuator systems. We specialize in the research, development and manufacturing of Linear Actuator, Control Box and Handset. Our products have passed QMS ISO9001 and Cert. CE. The products we produce are exported worldwide and widely used in medical, industrial, household and office fields, such as electric sofas, massage chairs, dental chairs, etc. With strict quality control and customer-oriented service spirit, we are always available to discuss your requirements to your satisfaction. And cost-effective and high-quality products will be designed and produced according to your request.
| Brand Name | HB |
| Model Number | HB-DJ801 |
| Input | 24vDC |
| Max Load | 6000N |
| Duty Cycle | 10% |
| Speed | 4~25mm/s |
| Stroke | 25~600mm( optional) |
| Min Installation Dimension | S≤400mm,L=175mm+S; S>400mm,L=200mm+S |
| Operation Temperature | -26 to +65 centigrade |
| IP Class | IP43 |
| Control Mode | Wired, Wireless |
| Limit Switch | Inner |
| Certificate | CE, ISO9001 |
| Material | Aluminum |
| Covering Color | Black |
| Place of Origin | Jiangsu, China |
Wuxi Hongba Mechanical Electrical Equipment Co., Ltd. is a joint-stock enterprise which specialized in the development, production, and sales of linear actuators. The company have been approved the QMS ISO9001: 2008 and Cert. CE/EMC + LVD and won the trust of "Quality Trustworthy Organization of JiangSu Province" and has independent import and export operation droit.
"HB" product is in great demand in China and International and widely used in the field of construction machinery, solar tracking, automation machinery, farm equipment and Intelligent furniture. The model such as HB-DJ808, HB-DJ806, HB-DJ828 in the industrial equipment, solar tracking and other fields share increased year by year.
We take"quality first, technology innovation" as the goal, making our products gradually to be the domestic first-class automatic transmission. HB have been knowing very well and approved by so many of our clients.
We are looking forward to establishing long-term cooperation and development and win-win business relationship with all the customers home and abroad.
