| Prod Model: |
HB-DJ802 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Input: |
24VDC |
| Load Capacity: |
1600n |
| Speed: |
16, 32mm/S |
| Application: |
Medical Bed, Furniture, Sofa |
Product Description
We are manufcture of linear actuator systems, waterproof and mini/heavy electric linear actuator, 12v /24v/36v/48v linear actuator.
Any interests, please let me know, I will try my best to recommend to you the right product.
Price:
Within 250mm (10inch) stroke, the Exw price of sample is the same price. More discount for you, if you place large order(more than 10pcs). As a manufacturer, our price is see-through.
Item strength datas
Input: 24VDC
Load Capacity: 1600N
Speed: 16, 32mm/s
Stroke: 50, 100, 200, 300mm-600mm (Optional)
Min Installation Dimension: 155mm
Characteristics
Limited Switch: Built-in
Operation Temperature: -40~65° C
Protective Class: IP43
Duty Cycle: S2-10min(operation 10mins constantly, rest 2mins)
Control Mode: Wired, Wireless(control box and hand controller avaliable)
Covering Color: Black
Application: Medical bed, funiture, sofa, TV stand
Routine product
Specially customized
The routine stroke or displacement is 330mm. It is enough for sofa and TV stand, But you need the more stroke, our engineer can design for you.
Transportation
1. All available shipping ways could be applied, by courier, air or sea.
2. Appointed shipping company or our own forwarders all could be used in shipment.
3. Full-way tracking the cargos for you before the goods arrive.
4. Working testing equipment to ensure every product can work normally before out of factory,
5. Our products are 100% been tested.
6. We can design for u about stroke, If you have any questions, please contact me.
Service
Quick reply to the customer's inquiry with 24hrs
Customized service available
Competitive Wholesale Prices
We offer you competitive wholesale price, you will be able to see the wholesale prices we offer for larger quantities shipped to you direct from China.
Also sample single-unit prices available by the request of our customers.
Sample Availability & Policy
We can offer one or more than one samples to the buyer.
The cost and freight charges should be paid by the customer, if you will place the large order.
Delivery time will take 7-10 business days.
--Working tempreture
The lowest tempreture: Minus 40 centigrate, but if you didn't inform us your application and working condition, we will do normally minus 25 centigrate.
--Material
Outer tube: Aluminum alloy
Inner tube: Stainless steel
--Warranty
One year quality guarantee
Oversea agent in US.
--please confirm the specific parameters
You typically select an actuation system by first identifying basic needs. Be clear about your requirements, from the load, speed, stroke and voltage.
Please confirm the parameters when you make a enquiry or place an order.
--the cost of shipping
The freight is up to your adress. Please attached the detailed adress in enquiry to quote you the fair freight. Thanks
Wuxi Hongba Mechanical Electrical Equipment Co., Ltd. is a joint-stock enterprise which specialized in the development, production, and sales of linear actuators. The company have been approved the QMS ISO9001: 2008 and Cert. CE/EMC + LVD and won the trust of "Quality Trustworthy Organization of JiangSu Province" and has independent import and export operation droit.
"HB" product is in great demand in China and International and widely used in the field of construction machinery, solar tracking, automation machinery, farm equipment and Intelligent furniture. The model such as HB-DJ808, HB-DJ806, HB-DJ828 in the industrial equipment, solar tracking and other fields share increased year by year.
We take"quality first, technology innovation" as the goal, making our products gradually to be the domestic first-class automatic transmission. HB have been knowing very well and approved by so many of our clients.
We are looking forward to establishing long-term cooperation and development and win-win business relationship with all the customers home and abroad.
