| Prod Model: |
TPA-SH0114 |
| Wall&Roof: |
Steel Sandwich Panel |
| Delivery Time: |
4 Weeks |
| Features: |
Waterproof,Fireproof,Sound Proof |
| Wall Panel Thickness: |
50/75/100/125/150mm |
| Material: |
Sandwich Panel |
| Usage: |
Workshop |
| Certification: |
SGS |
| Customized: |
Customized |
Product Description
Product Information
Product type:Prefab T type house
Two storey eco modular prefabricated housing for living quarters
1.Qualified Structure and Material
2.Flexible Design
3.Fast Installation
4.Reasonable Cost
5.Assembling for several times
-Prefabricated housing are making full use of the strengths of sandwich panel, wall panel and roof panel and through the connection with screws, bolts and self-tapping screws.
-Prefabricated housing can be used as temporary offices, meeting rooms, headquarters, dormitories, temporary school etc.
Prefabricated house material# Steel framework
Main column: fabricated by 80*80 or 100*100 or 120*120 or 150*150 Square Tube, Q235
Steel Surface working: Alkyd painting,two primary and two surface.
Main triangle Beam: fabricated by C80, C100, C120, C140 Section steel.
Wall and roof purlin: C80, C100, C120, C140 Section steel, Q235 Steel.
# Ceiling Construction
6mm Gypsum board for dry room
12mm PVC ceiling for wet room
# Walls/roof
50mm/75mm/100mm/125mm sandwich panel + PVC clading for the wall
50mm/75mm/100mm/125mm sandwich panel+Asphalt shingles for the roof
# Door
External door:steel door with opening dimension 950*2100mm, furnished with lock with 3keys.
Inner door:sandwich panel door just as the wall materials
# Windows
Window material: PVC window with fly screen, 4mm glass.
#Electrical fittings option
Electrical wire, 2.5mm2 for lighting system, and 4mm2 for AC units.
16A five hole universal socket.
double tube fluorescent lamp, 220V,50-60HZ
Single Switch, Honyar brand, with junction box
Electrical distribution box, box+breakers+earth leakage protective device
#Optional Water system fittings
Water drain pipe, PPR pipe, dim 16-20mm, connection fittings are made of copper or pvc,
Exhaust fan or air exchange hole, size 250mm*250mm made of steel or PVC
#Sanitary ware
Close tool: ceramic, with pipes and installation fittings
Urinal: ceramic, with pipes and installation fittings
Wash basin: ceramic, with post, faucet, pipes and installation
Prefabricated housing advantages:1)Easy to assemble and disassemble:light weight, 20~30m2 per day per people.
2)Safe & steady: seismic capability grade 7, anti-wind capacity grade 7, floor loading 1.5KN/M2.
3)Flexible layout: Various modular combinations, doors & windows could be fixed optional.
4)Durable,water proof and preventing rust: ALL the light steels dealed with anticorrosive paint.
5)Energy saving & Eco-friendly: Energy-efficient, no construction garbage, recycle use.
6)Low material cost and labor cost: Cheaper than tranditional buildings.
7)Longevity:It can work for more than 10 years under peoper use.
8)Easy to load & delivery: 300~350m2 per 40 HQ.
Simple design two storey prefab house for laborWe offer economic style, standard style and luxury style for your choice and customise designs and requirements are welcome. We also offer C style steel material lines, color steel sheets and corrugated sheets.
Prefabricated house benefit
| Time-saving | Cost Reduction | Anti-earthquake | Fresh Air Inside |
