| Prod Model: |
NWI-4000T |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Cooling Capacity: |
2000rt |
| Cooling Media: |
PVC/PP Film Fill |
| Application: |
Sugar Plant |
| Motor Brand: |
Siemens/ABB |
| Tower Frame Material: |
Hot DIP Galvanized Steel(Hdgs) |
| Casing And Water Basin: |
FRP/Concrete/SUS304 |
| Foundation: |
Concrete #C20 |
| Service Life: |
25years |
| Guarantee: |
2 Years After Start up |
| Brand: |
Newin |
| Cooling Method: |
Counter Flow |
| Material: |
FRP |
| Certification: |
CTI |
| Condition: |
New |
Product Description
Features:
None-easy blocked design
Excellent Design and Long lifetime.
The shell of cooling tower adopts high quality and toughness glass fiber, beautiful shape, resistants to natural factors and chemical material erosion, looks brand new even after long time use. All the steel shelves are processed by immersive hot galvanized zinc and comply with British BSENISO1461: 1999 standard, reducing the oxidation mostly, prolong the service life.
High Efficiency and Energy Saving
Newin NWI series cooling tower using excellent quality PVC film as thermal interface material, corrosion resistant, no deformation, curved and diagonal design film effectively prolongs exchange time between high temperature water and air inside cooling tower, which makes air flow smoothly and resistance lower, meanwhile, making the water drift ratio lowest, furthermore, the axial and arc fan, specially designed basin with evenly distributed waterstoma, which highly improved heat exchange rate of cooling tower and lower the entire cooling tower's energy consumption and noise.
Easy Installation, Reasonable and Practical Usage
Newin NWI series cooling towers can be paralleled for multi-units, flexible combination, widely used. The body structure is tidy, standardized, compact and strong, which is easy for installation. The design and manufacture are all on basis of practical uses, so it can meet customers' requirement better with high quality.
| Model | NWI | 800 | 1000 | 1500 | 2000 | 2500 | 3000 | 3500 | 4000 |
| Nominal flow | m 3 /h | 800 | 1000 | 1500 | 2000 | 2500 | 3000 | 3500 | 4000 |
| Cooling capacity | Kcal/h | 8.0×10 6 | 1.0×10 7 | 1.5×10 7 | 2.0×10 7 | 2.5×10 7 | 3.0×10 7 | 3.5×10 7 | 4.0×10 7 |
| Water pressure | ×10 4 pa | 8.0 | 8.8 | 10.0 | 11.0 | 11.5 | 12.0 | 13.3 | 13.5 |
| Net weight | Ton | 11.63 | 19.68 | 29.34 | 45.03 | 46.2 | 65.0 | 76.05 | 78.5 |
| Running weight | Ton | 18.45 | 31.23 | 46.75 | 68.69 | 75.3 | 99.2 | 104.8 | 132.0 |
| Noise | dB(A) | 71 | 72 | 72.5 | 73 | 73.5 | 73.5 | 74 | 74 |
| Air volume | km 3 /h | 600 | 900 | 1200 | 1750 | 2100 | 2400 | 2730 | 3150 |
| Fan diameter | mm | 4700 | 5460 | 6000 | 7700 | 8000 | 8530 | 9140 | 9140 |
| Motor power | kW | 30 | 45 | 55 | 90 | 132 | 160 | 160 | 200 |
| Motor speed | rpm | 220 | 165 | 165 | 149 | 149 | 149 | 110 | 110 |
| Length | mm | 7400 | 9000 | 10500 | 12000 | 13500 | 15000 | 16000 | 17400 |
| Width | mm | 7400 | 9000 | 10500 | 12000 | 13500 | 15000 | 16000 | 17400 |
| Height | mm | 7800 | 8700 | 9500 | 10200 | 10700 | 11400 | 12100 | 12400 |
| Fan stack height | mm | 2800 | 3100 | 3600 | 3800 | 4000 | 4200 | 4400 | 4400 |
| Coaming height | mm | 3500 | 3800 | 3800 | 4000 | 4000 | 4200 | 4500 | 4500 |
| Air inlet height | mm | 1500 | 1800 | 2100 | 2400 | 2700 | 3000 | 3200 | 3500 |
| Water inlet height | mm | 4000 | 4300 | 4600 | 4900 | 5200 | 5500 | 5700 | 6000 |
| Water inlet diameter | mm | 400 | 450 | 500 | 450*2 | 450*2 | 500*2 | 500*2 | 550*2 |
| Fan stack | Fiberglass Reinforced Polyester |
| Exhaust fan | Completed equipment |
| Ladder | Galvanized steel |
| Roof plate | Fiberglass Reinforced Polyester / Gavanized steel |
| Water eliminator | PVC |
| Sprinkler system | Galvanized steel & P.V.C |
| Infill | PVC |
| Casing | Fiberglass Reinforced Polyester |
| Ice-melting pipe | Galvanized steel |
| Clapboard | Fiberglass Reinforced Polyester |
| Frame | Galvanized steel / Concrete |
| Pool | Concrete |
