| Prod Model: |
THR-FC001 |
| Certificate: |
Ce, ISO, TUV |
| Made: |
100% Stainless Steel |
| Heating Time: |
10-20mins Reach 80-110 Degree |
| Heating Power: |
3.6-4.2kw |
| Working Voltage: |
220-380V |
| Temp Controller: |
0-120degree |
| Humi Controller: |
0-99% |
| Warranty: |
18months |
| Customer Required Size: |
Available |
| OEM: |
Available |
| Usage: |
Hospital |
Product Description
! ! ! Hot sales THR-FC001 Electric heating food cartSize: 1250*540*980mmSpecification:1. Insulated food trolley's capacity of food plate 48PCS
2. Heating time(80-110degree)10-20M
3. Heating power: 3.6-4.2KW
4. Working voltage: 220-380V
5. Weight: 115kg
Standard Accessories:Stainless steel fast foot plate: 48PCS
Stainless steel soup bucket: 2PCS size: 200*290*290mm
Stainless steel plate: 4PCS size: 400*320*40mm
Installation: The main cart and electric controller box are separated. When installing the electric controller box, should be connected with earth well. Also our food cart can be used as food deliver cart without electric controller box.
Operating Methods:1. When the food cart in working contitions, should be placed in the horizontal ground.
2. Inject enough clean water to the water plate in the bottom of the cart.
3. Put in all the foods to the cart, close the airproof-door.
4. Connect the food cart with electric controller box, also connect with power.
5. Push the switch to turn on the food cart, the light indicator in green show us in working condition. The working time could be fixed 1-20mins according to detail requirement.
6. When heating for10-20mins, power would be cut off automatically by the time-controller.
7. Checking the temperature on the board, should be 80-100degree. Because of the Heat retaining functions, the temperature will raise about 10degree.
8. As to different temperature each season, the heating time should be fixed flexible.
| Standard accessory |
| Stainless steel fast food plate Size: 270*210mm, 360*270mm | 48pcs |
| Stainless steel soup bucket Size: 200*290*290mm | 2 pcs |
| Stainless steel big food plate Size: 400*320*40mm | 4 pcs |
| Temp controller box | 1 pc |
| Stainless steel handle | 2 pcs |
| Large rubber castors | 4 pcs |
