| Prod Model: |
00 |
| Car Walls: |
Stainless Steel / Painted |
| Elevator Type: |
Passenger Elevator, Villa Elevator etc. |
| Warranty: |
1 Year |
| Delivery Time: |
20 Days |
| Floor: |
PVC or Marble |
| Application: |
Mr or Mrl |
| Car Frame: |
1:1 or 2:1 |
| Door: |
Optional |
| Cop/Lop: |
Optional |
| Driving Type: |
AC Elevator |
| Capacity: |
320-1600kgs |
| Persons: |
4-21 Persons |
| Speed: |
0.5-4.0m/S |
| Position Of Computer Room: |
Mr or Mrl |
| Elevator Door: |
Automatic or Semi-Automatic |
Product Description
1. We can supply different types of cabin as below:
Application |
Passenger Elevator, Cargo Freight Elevator, Car Elevator, Villa Elevator, Hospital Elevator etc. |
Cabin finish |
Painted, HSS, Mirror Etching SS, Golden SS, Black Titanium SS |
2. Ceiling, handrail and floor can be opitonal.
3. Nova standard cabin includes several assemblies listed as below:
3.1) Car Wall: Back Wall + Left Wall + Side Wall + Front Wall
3.2) Car Celling: LED
3.3) Car Floor: PVC or Marble
3.4) Handrail: Round or Flat
4. Nova standard car frame includes several assemblies listed as below:
4.1) Cross Beam(1 PC), Upright(2 PCS)and Bottom Beam(1 PC)
4.2) Limit Switch Touching Plate (1 PC)
4.3) Car Side Pulling Rod (4 PCS)
4.4) Oil Can (2 PCS)
4.5) Guide Shoes (4 PCS)
4.6) Lifting Pulling Rod For Safety Gear (1 PC or 2 PCS)
4.7) Safety Gear (1 Pair)
4.8) Safety Gear Linkage (1 PC)
4.9) Safety Gear Switch (1 PC)
5. Besides, we also supply extra assemblies as below:
5.1) Suppoting Bracket
5.2) Load Weighing Device
5.3) Buffer Striking End
5.4) Suspension Device(rope suspension or pulley sheave)
If you are interested in our cabin, pls feel free to contact us as below:
Contact Person |
Lily Wang |
TEL.: |
0086-512- 5677 1008 |
FAX: |
0086-512-5879 5609 |
Web: |
http://www.novaelevator.com
http://www.cnnovaelevator.com |
|
novaelevator06 |
NOVA ELEVATOR PARTS Co., Ltd. Was established in 2002 by people with long term technical experience both in China and International elevator market.
We are the modern manufacturer of lift components, well equipped with advanced machinery capable of producing high quality products including Guide Rails, Cabin, Counterweight, Door System, Eletrical System etc. Our more than 10 years of hands-on manufacturing experience have allowed us to steadily fine-tune our production techniques, improving every single process involved and optimizing the fitness of each and every component to the final product. Combining the manufacturing with the trading activities we are in place to supply full range of components for modernization lifts or complete new lift, while always retaining high quality and reliability.
Our policy is to offer our customers direct and complete support, in terms of materials, components and services provided before and after every sale.
As we move forward, we will continue our commitment to excellence and offer best value for our esteemed customers.
