| Price: | US $ 2.35-2.98KG |
|---|---|
| Min Order: | 500KG |
| Pay Type: | L/C,T/T,Western Union,Paypal |
| Prod Model: | EP-W |
|---|---|
| Gloss: | 10% |
| Thickness: | 50-70um |
| Hardness: | 2h |
| Adhesion: | 0 Grade |
| Impact Resistance: | 50kg/Cm |
| Appearance: | Powder |
| Paint Film Property: | Antiseptic Paint |
| Method: | Spray |
| Level: | Finish Coat |
| Certification: | Reach, FDA, En71 |
| Components: | Film Forming Matter |
| Formation Mechanism: | Conversion Type |
| Substrate: | Metal |
| Main Raw Material: | Epoxy/Polyester |
| Color: | Ral9003 White |
| Product Details | |
| Type | RAL9003 White Sand Texture Powder Coating For Iron Bookshelf |
| Color | RAL9003 White |
| Surface Finish | Sand Texture |
| Gloss level | 10%±5% |
| Particle Size | Average 32-42μm |
| Specific Gravity | 1.2-1.7g per cubic meter |
| Coverage | 6-8 square meters per Kg at 30-90 μm film thickness |
| Film thickness | 50-70um |
| Application Recommendation | |
| Application Voltage | 40-60 KV |
| Gun to Component Distance | 15-30CM |
| Curing Temperature | 200ºC X 10min |
| Powder coated Film Mechanical Properties | |
| Adhesion | Cross-cut(2mm), no loss of adhesion |
| Impact Resistance | Direct impact 50kg/cm |
| Pencil Hardness | 2H |
| Cupping Test | 6mm Mandrel |
| Bending Test | 5mm |
| Powder Coated Film Chemical Resistance | |
| Salt Spray Test | 5% NaCl Solution for 500 hours - No change |
| Acid Resistance | 5% HCl for 48 hours DIP test - No change |
| Alkali Resistance | 5% NaOH for 48 hours DIP test - No change |
| Storage Stability | |
| Store in ventilated, dry, clean room, temperature < 25ºC | |
| Relative humidity 50-65% | |
| Away from direct sunlight, fire, heat | |
| For best performance, use within 6 months | |
| Gloss | 1. High gloss(above 80%), semi gloss(40-79%), matt gloss(5-39%) and no gloss(below 10°) 2. Gloss and texture can be customized as clients require |
| Curing Condition | 1. Standard curing (200ºC×10min) 2. Lower temperature curing (180ºC×15min) |
| Color | 1. RAL & Pantone Colors are available 2. Colors can be customized as clients require |
| Standard | Special standards of product are available according to clients' requirements, e. G. RoHS standard, EN-71, FDA, LFGB, etc. |
| Property | Excellent physical performance in hardness, flexibility and adhesion...Good mechanical properties, outstanding heat resistance, fine corrosion, weather and chemical resistance. |
| Storage | 1. The product can be stably stored for at least half year when kept in closed containers in a dry place at temperature below 25°C. 2. Keep it away from fire, heat and direct sunlight. 3. Avoid rains and exposure to sunshine during shipment. |
