Outdoor Cabinets

Name: Outdoor Cabinets
Brand: thisfurniture.com
SKU: 835881315
Availability: InStock
Rating: 4.9 (142 reviews)

Price:	US $ 12-28/Piece
Min Order:	100/Piece
Pay Type:	T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	XJBS-A
Thickness:	1.2mm
Color:	Ral 7032
Paint Finish:	Poxy Polyester Powder Coating
Customized:	Accepted
Type:	Power
Structure:	Fixed Board
Shell Protection Grade:	IP65
Brand:	Xjele

Product Description

Material
Body : 1.2mm sheet steel till size XJBS-A 8060/20 then 1.5mm
Mounting plate : 1.5mm sheet steel till size XJBS-A 8060/20 then 2.0mm
Door :1.2mm sheet steel till size XJBS-A 8060/20 then 1.5mm
Surface finish
Body and door :Epoxy polyester powder coating textured finish
Mounting plate: Epoxy polyester powder coating flat finish
Color
Body and door :RAL7032/RAL7035
Mounting plate: RAL 2000 OR galvanized steel

Protection degree:IP 65
Against mechanical impacts: IK10

Supply:Enclosure, door ,Galvanized or orange painted mounting plate, locking system, gland plate, sealing gasket and fixing accessories.

Customized size, thickness, process requrements is accepted.
waterproof outdoor electrical power wall mount enclosures

MODE	DIMENSION			MODE	DIMENSION
	DIMENSION				DIMENSION
	H(MM)	W(MM)	D(MM)		H(MM)	W(MM)	D(MM)
XJBS-A 2020/15	200	200	150	XJBS-A 6060/30	600	600	300
XJBS-A 2520/15	250	200	150	XJBS-A 7050/15	700	500	150
XJBS-A 3020/15	300	250	150	XJBS-A 7050/20	700	500	200
XJBS-A 3025/20	300	250	200	XJBS-A 7060/20	700	600	200
XJBS-A 3030/15	300	300	150	XJBS-A 7060/25	700	600	250
XJBS-A 3030/20	300	300	200	XJBS-A 7060/30	700	600	300
XJBS-A 3030/25	300	300	250	XJBS-A 8060/20	800	600	200
XJBS-A 4030/15	400	300	150	XJBS-A 8060/25	800	600	250
XJBS-A 4030/20	400	300	200	XJBS-A 8060/30	800	600	300
XJBS-A 4030/25	400	300	250	XJBS-A 8080/20	800	800	200
XJBS-A 4030/30	400	300	300	XJBS-A 8080/25	800	800	250
XJBS-A 4040/15	400	400	150	XJBS-A 8080/30	800	800	300
XJBS-A 4040/20	400	400	200	XJBS-A 10060/20	1000	600	200
XJBS-A 4040/25	400	400	250	XJBS-A 10060/25	1000	600	250
XJBS-A 4040/30	400	400	300	XJBS-A 10060/30	1000	600	300
XJBS-A 5030/15	500	300	150	XJBS-A 10070/20	1000	700	200
XJBS-A 5030/20	500	300	200	XJBS-A 10080/20	1000	800	200
XJBS-A 5030/25	500	300	250	XJBS-A 10080/25	1000	800	250
XJBS-A 5040/15	500	400	150	XJBS-A 10080/30	1000	800	300
XJBS-A 5040/20	500	400	200	XJBS-A 10080/40	1000	800	400
XJBS-A 5040/25	500	400	250	XJBS-A 100100/25	1000	1000	250
XJBS-A 5040/30	500	400	300	XJBS-A 100100/30	1000	1000	300
XJBS-A 5050/20	500	500	200	XJBS-A 12060/20	1000	600	200
XJBS-A 5050/25	500	500	250	XJBS-A 12060/25	1000	600	250
XJBS-A 5050/30	500	500	300	XJBS-A 12070/25	1000	700	250
XJBS-A 6040/15	600	400	150	XJBS-A 12080/20	1000	800	200
XJBS-A 6040/20	600	400	200	XJBS-A 12080/25	1000	800	250
XJBS-A 6040/25	600	400	250	XJBS-A 12080/30	1000	800	300
XJBS-A 6040/30	600	400	300	XJBS-A 12080/40	1000	800	400
XJBS-A 6050/15	600	500	150	XJBS-A 120100/25	1200	1000	250
XJBS-A 6050/20	600	500	200	XJBS-A 120100/30	1200	1000	300
XJBS-A 6050/25	600	500	250	XJBS-A 120100/40	1000	1000	400
XJBS-A 6050/30	600	500	300	XJBS-A 14060/40	1400	600	400
XJBS-A 6060/15	600	600	150	XJBS-A 14080/40	1400	800	400
XJBS-A 6060/20	600	600	200	XJBS-A 140100/40	1400	1000	400
XJBS-A 6060/25	600	600	250	XJBS-A 140100/40	1400	1000	400
More dimension information, please contact with us.
website:www.xujieelec.com

powder coating spray Mild Sheet steel metal Outdoor waterproof distribution box,electrical wall mounted control panel electrical switchboard,spray paint IP66 waterproof metal distribution box,power distribution box,Electrical enclosure distribution box,Power distribution box,Waterproof metal enclosure distribution box,Industrial steel distribution box,wall mounted galvanised distribution box,wall mounted switch electric control panel,distribution box metal electrical distribution panel board enclosure,power control cabinet , powder coating spray steel electrical power switch box ,switching control double door electrical panel control cabinet, electrical panels IP66 Power wall mount small metal box.Waterproof metal electrical distribution board box

Wenzhou Xujie Electric Co. Ltd is located in Yueqing China. We are a professional committed to production, research and development, and sale of wall-mounted sheet steel electric enclosures, non-standard irons, stainless steel, aluminum alloy, plastic electrical, electronic cabinets and boxes, terminal.

Exporting Products Worldwide

With "The best for you" motto, we combined innovation and high quality. We want to be your best choice for distribution box and cabinet. Our products are sold widely to more than 30 countries and regions.

We accept customized and design together, if you have any special requirement. For more detailed information, contact us today.
