| Prod Model: |
YJ-EB-B2 |
| Model: |
Yj-Eb-B2 |
| Bed Body Size: |
L1250*W950*H420-620mm |
| Overall Lifting: |
420-620mm |
| Back Adjustment: |
80 +- 5 Degree |
| Leg Adjustment: |
40+-5 Degree |
| Scale: |
Large |
| Color: |
White |
| Function: |
Patient Using |
| Load Capacity: |
Over 240kg |
| Frame: |
40 * 60 * 1.5mm |
| Type Of Hospital Bed: |
Nursing Bed |
| Folded: |
Unfolded |
| Numbers Of Function: |
Three-function |
| Certification: |
ISO13485 |
| Material: |
ABS Advanced Engineering Plastics |
| Using Ambient: |
Hospital Clinical |
Product Description
Product Features:
1.Bed, bed tail using ABS advanced engineering plastics from a plastic injection, beautiful appearance, loading and unloading freely, impact resistance, heat resistance, low temperature resistance, chemical resistance and electrical performance.
2. Fence with folding fence, pipe for the high-quality aluminum alloy material, fence column up and down connection for the ABS plastic material, durable, easy to use, guardrail handle with anti-clip design, can not be folded when used on the bed frame, easy to operate.
3.Four rounds of 125mm luxury mute control wheel, high stability linkage system. Brake stability is flexible and convenient. Waterproof, dustproof. Double round cake design to increase the ground area. Increase stability.
4.Bed panel is made of one-step molding coldrolled steel, thickness 1.2mm, concave multi-stomatal design, with excellent performance in anti-slipping and air permeability. Surface without solder joints, the back of steel pipe ribs, the use of double support unloading structure, to extend the life of the bed.
5.Bed frame with 40 * 60 * 1.5mm shaped square tube welded. Advanced welding process. Welding quality good made The bed is strong.Load capacity over 240kg.
6.The whole bed with acid pickling, phosphating, washing, oxidation and a series of processes, automatic water spray line, the use of Aksu powder electrostatic spraying, bright color, attached firmly.
7.Full voltage motor three groups, a set of control box,;all-round handhold control panel;can be completed back fold, leg fold, the overall lift, three functions.
Main Parameters:
| Model | YJ-EB-B2 |
| Bed body size | L1250*W950*H420-620mm |
| Overall lifting | 420-620mm |
| Back adjustment | 80 +- 5 degree |
| Leg adjustment | 40+-5 degree |
Configuration:
| Standard | Optional |
| 1 pic European bed head | Semi - brown half - cotton tarpaulin special mattress |
| 3 groups motor,1 control box | Shelf |
| 2 pics Drainage hook | Stainless steel telescopic infusion stand |
| Aluminum alloy six gear fence | Table board |
| 4 Infusion jack | ABS bedside cabinets |
| 1 set Luxury control wheel | Escort chairs |
