| Prod Model: |
HTJG |
| Platform Size: |
2.5*2.5 |
| Lifting Height: |
10m |
| Power: |
AC,Bc |
| Loading Capacity: |
Customised |
| Lifting Platform: |
Anti-Skid and Anti-Drop |
| Structure: |
Scissor |
Product Description
Product Description
hydraulic stationary scissor lift table
1. hydraulic scissor lift introduce
---It is used to convey the goods from one working level to another.
---The control panels are available at the designated floors and one the lift platforms.
---Heavy capacity,platform size and lifting height can be chosen according to your actual needs.
2. mini scissor lift advantages:
---Installed in the pit,do not occupy space.
---When lifting up or down, up,down and stop three buttons control the lift.
---Great load capacity, 120% capacity load test. skidproof platform.
---Sensitive overload protection devices locking device for failing protection.
3. Model list-for your reference
Pls note: The lift table is customized, so pls kindly confim the lifting height, platform size
and load capacity you need.
| Model | Load | Platform size | Lifting height | No-working height | Power |
| SSL3-2.4 | 3T | 2.0*2.0M | 2.4M | 660MM | 4KW/380V |
| SSL2-5.0 | 2T | 2.1*1.2M | 5.0M | 870MM | 4KW/380V |
| SSL3-6.5 | 3T | 2.2*1.9M | 6.5M | 1520MM | 5.5KW/380V |
| SSL1.5-3.8 | 1.5T | 2.2*2.0M | 3.8M | 700MM | 4KW/380V |
| SSL2-6.0 | 2T | 2.0*1.3M | 6.0M | 1200MM | 4KW/380V |
| SSL1.5-0.8 | 1.5T | 2.0*1.5M | 0.8M | 500MM | 3KW/380V |
| SSL1 -4.3 | 1T | 2.0*1.8M | 4.3M | 800MM | 4KW/380V |
we can design our hydraulic stationary scissor lift table with your plan
Features:
a.Can be floor-mounted or pit-mounted. The former is to be sited on a special place to loading cargos and then lifting to a certain height to handle and move the cargos.The latter is sited in a pit . The table of lift is in the same level with the ground which is convenient to move the cargo onto it.
b.Streamline goods handling operation
c.Many safety facility and accessory can be added or customized to suit to different demands.
d.Very solid and durable material for chequered plates and cylinders.
e.1 year warranty
Safety Precaution:
1). Explosion-proof valves: protect hydraulic pipe, anti-hydraulic pipe rupture.
2). Spillover valve: It can prevent high pressure when the machine moves up. Adjust the pressure.
3). Emergency decline valve: it can go down when you meet an emergency or the power off.
4). Anti-dropping device: Prevent falling of platform
.Our company Information
HONTYIIFT MACHINARYco.ltd has devoted itself to the research and development, design and manufacture, salesand service of scissor lift, cargo lift and other hydraulic equipment. As a more than 8 years
export experience supplier of hydraulic equipments supplier, Sinicmech machinery has
more than 20000 square meters producing shop and assembly shop.
That we have many advanced production equipment for cutting steel structure, machine
parts, including scissor structure, platform, hinge pin, beams, articulated boom and other
small parts. which made the precise scissor lift structure and boom lift, beams, and even
the small needed parts, this is a great improve for our products quality and user's safety.
Our services
1. Presale service:
Free comprehensive and detailed technology consultancy in construction sites, referential programs for construction equipment and the most suitable product program.
2. In sale service:
We provide free guidance of installation and debugging and free training of operation, care and maintenance.
3. After-sale service:
One year warranty service of whole machine and lifetime maintenance; regularly markets visits and free guidance of whole machine's maintenance and reparations.
4. Quick responses:
we have a complete service network, hotline(86-531-88890369) services for 24hours and assist you to solve the problem in a short time.
5. Parts supply:
we have a complete parts supply network and can guarantee sufficient parts reserves and timely supply.
If you are interested in hydraulic stationary scissor lift table ,please contact us .
