Suzhou Thriving Medical Equipment Corp. >> Hospital Multifunction Electric Donation Chair (THR-DC510)

Hospital Multifunction Electric Donation Chair (THR-DC510)

Hospital Multifunction Electric Donation Chair (THR-DC510)
Price: Negotiable/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 1/Piece
Pay Type: L/C,T/T,Western Union
Prod Model: THR-DC510
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Size: L1880mm*W920mm* H560mm
Leg Segment Angle: -80°-10°
Caster: Dia.100mm
Electric Donnation Chair OEM: Available
Back Segment Angle: -10°-80°
Height Adjustment: 290mm
Function Control Way: Electric Motors Control Adjustment
Maximum Safe Load: 240kg
Seat Segment Angle: 0°-30°
Motors: 3 PCS

Product Description




Product Description
THR-DC510 Medical electrical dialysis chair

Modern design, high quality materials and detailed finishing of the upholstery,
As well as mechnical and electrical parts underline the high standard of the comfort-line.
Continuous adjustment to all sitting and lying positions.
A 3-dimensional adjustable armrest,
An electrically adjustable footrest,
As well as a height adjustable headrest provide comfort for your patients.
The base frame with a maximum safe load of 240kg,
Offers a high stability also in the horizontal position.

-Humanization and Comfortable design
Taking the aero seat as the prototype improvement, upholstery with polyurethane, luxurious, comfortable and durability. We've designed the chair to work with a patient's body.

-Multi-position adjustment:
Adjusting backrest and legrest, the overall increase and full trendelenburg position by electromotion through reliable static motor.

Saving Space:
-Only 1.2 Square Meters. Space required, saving about 40% space than the tradition medical bed.

Dimension
Adjustments
Seat segment width600mmBack segment angle-10° -80°
Chair width, including armrests920mmSeat segment angle0° -30°
Total length1880mmLeg segment angle-80° -10°
Total weight85kgHeight adjustment290mm
Ground clearance120mm
Caster  dia. 100mmElectrical specifications
Back cushion190*490*120mmPower supplyAV220± 20V/50HZ 100VA
CushionPU foamMotors  3
Upholstery  PVC leather
FrameQ235 steelSafe maximum load240kg

Suzhou Thriving Medical Equipment Corp., was established in 2000. We are mainly engaged in hospital furniture, medical equipments, and funeral products etc. With strong technical force, advanced equipment and five large-scale production lines, we can complete deep processing of various metal products, specializing in the furniture and hardware products. In order to best meet customers' requirements, we have implemented a quality control system that is in strict accordance with ISO9001 standards.

Abut on Shanghai, Suzhou, Wuxi, Changzhou and other medium-large cities, we enjoy very convenient transportation arising from the Huning Expressway, Riverine expressway, Zhangjiagang port and Shanghai port. This advantageous geographical position has also facilitated our products' exportation and helped us expand overseas market and seek for overseas partnership.

Adhering to the management principle of 'Honesty, Dependence, Advance, Innovation', we offer excellent service and superior quality products at very competitive price to customers from around the world. Please feel free to contact us for more details.
