Fujizy Passenger Lift

Prod Model:	FJK8000-1
Model:	Fujizy Elevator
Machine Room:	Yes
Floor:	10,or as Your Needs.
Cabin Material:	Stainless Steel
Traction:	Gearless Traction Machine
LED Car Lighting System:	Yes
Energy Feedback System:	Yes
Certificates:	Ce,ISO9001
Location:	Shandong
Warranty:	1 Year
Driving Type:	AC Elevator
Capacity:	500-1000kg
Persons:	6 - 10
Speed:	1.00 - 2.00m/s

Product Description

Products Introduction:


Rated Loading Capacity	Rated Speed	Cab Size Width*Depth	Door Size Width*Height	Shaft Size Width*Depth	Machine Room Size	Min Overhead	Pit Depth
kg	m/s	mm	mm	mm	mm	mm	mm
630	1.0	1400*1100	800*2100	1900*1850	1900*1850	4400Min	1500Min
	1.5					4600Min	1600Min
	1.75					4700Min	1700Min
800	1.0	1400*1350	800*2100	1900*2100	1900*2100	4400Min	1500Min
	1.5					4600Min	1600Min
	1.75					4700Min	1700Min
	2.0					5000Min	2000Min
1000	1.0	1600*1400	900*2100	2100*2150	2100*2150	4400Min	1500Min
	1.5					4600Min	1600Min
	1.75					4700Min	1700Min
	2.0					5000Min	2000Min
	2.5					5000Min	2200Min
	3.0					5500Min	2600Min
	4.0					6500Min	3800Min
1150	1.0	1800*1400	1000*2100	2300*2150	2300*2150	4400Min	1500Min
	1.5					4600Min	1600Min
	1.75					4700Min	1700Min
	2.0					5000Min	2000Min
	2.5					5000Min	2200Min
	3.0					5500Min	2600Min
	4.0					6500Min	3800Min
1250	1.0	1800*1500	1000*2100	2300*2250	2300*2250	4400Min	1500Min
	1.5					4600Min	1600Min
	1.75					4700Min	1700Min
	2.0					5000Min	2000Min
	2.5					5000Min	2200Min
	3.0					5500Min	2600Min
	4.0					6500Min	3800Min
1350	1.0	2000*1500	1100*2100	2500*2250	2500*2250	4400Min	1500Min
	1.5					4600Min	1600Min
	1.75					4700Min	1700Min
	2.0					5000Min	2000Min
	2.5					5000Min	2200Min
	3.0					5500Min	2600Min
	4.0					6500Min	3800Min
1600	1.0	2000*1750	1100*2100	2500*2500	2500*2500	4400Min	1500Min
	1.5					4600Min	1600Min
	1.75					4700Min	1700Min
	2.0					5000Min	2000Min
	2.5					5000Min	2200Min
	3.0					5500Min	2600Min
	4.0					6500Min	3800Min



Company Introduction:

Shandong FJZY Elevator Co., Ltd. is a large-scale FJZY Elevator production base in China mainland . It has introduced the high FJZY technology as the specialized professional enterprise with the integration of manufacture, sales, installation, maintenance and transformation. The manufacturing plant is located in Ningjin of Shandong Province 'Hometown of Elevator' and 50km away from Jinghu Expressway and 100km from Jinan Yaoqiang Airport.
   Company invested 60 million RMB in 2008, built plant area of 89 acres, an area of 26,000 modern factory. Employee enrolled nearly 200 people. It has 80 engineers and technicians and 30 senior quality controllers. The company has also introduced a large number of international advanced equipments including numerical control laser machines, imported numerical control machining center, imported bender, imported plate shearing machine and large-scale chalk line.
   Based on the solid comprehensive production advantage in mechanical and electrical products of Fuji Group, the company applies the advanced Fuji electrical components of modular structure into the elevator control system to equip the elevator with the features of safety, reliability and environmental protection. It now manufactures passenger elevator of standard machine room, small machine room and machine-room-less of variable frequency, voltage and speed, passenger-goods elevator, hospital bed elevator, residential elevator, panoramic elevator, escalator and moving walk. It can also customize various kinds of non-standard elevator according to the demands of customers.
   Company invested 216 million RMB in March, 2010, and go on the second phase of the expansion project, with a area of 150 acres. Office building has a area of 5,000 square meters, 40,000 floor space. Elevator testing tower has a height of 100 meters, the annual production capacity is 6000-8000 units. The company adheres to the safety, energy saving, high quality corporate philosophy, follows the professional and international modern management methods of elevator. And the ISO9001 quality management system is required.
  Insisting on implementing international strategy, Shandong Fuji Zhiyu Elevator Co., Ltd. is making continuous efforts to be an elevator manufacturing enterprise with international competitiveness and internationally top standard in elevator network of design, production, marketing, installation and after-sale service . Through unremitting efforts, currently, Fuji elevator has been widely approved by partners and customers in the aspects such as the development, production, installation, maintenance and transformation technology of elevator, stair and sidewalk. The successful installation and application of a great number of projects in Shandong, Hebei and Tianjin indicate that Fuji Elevator as a professional elevator production enterprise with internationally leading technical level and nationally Grade A authentication speaks with strength and sets up brand with quality. In the brand-new year, our company will keep going and continue providing service for the social customers for the purpose of integrity, quality and service.

We are looking for agents worldwide.Welcome to visit our company for cooperations!
