| Prod Model: |
SS-18-2X750 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Motor: |
Cummins |
| Application: |
Mining |
| Installation: |
Offer Foundation Drawing, Guided |
| Guarantee: |
1 Year(Wearing Parts Excluded) |
| Spare Parts Supply: |
The Whole Life |
| Type: |
Beneficiation Machinery |
| Mining Object: |
Coal Machinery |
Product Description
(1) Mining Machine/ Sand Collecting Machine(SS series) Introduction
The SS series sand collecting system---- Crushing machine/mining machine is designed on the base of absorbing the foreign advanced technology, together with our real condition and come up to the advanced world standard. They are utilized widely in the sandstone aggregate processing system of water and electricity station, the processing system of original glass material, the production line of manufactured sand, recovery of the coarse slime of the coal cleaning factory, and the protection environment project(the mud cleaning etc. ) and so on, they can solve the fine sand recovery questions.
(2) Work Principle
1. The system is composed of the motor, pump, cyclone, vibrating screen, pool, recycling box
2. Working principle: The compound of sand and water is transported to cyclone, the sand that centrifugal classification concentrate provided to the vibrating screen by the heavy grit, sand and water are effectively separate after vibrating screen dehydration. Through Recycling Box, fine sand and mud and so on returned again to the pool, then are exhausted from the exit when the liquid surface of pool is too high. The material weight concentration recovered by the vibrating screen is 70%- 85%. Adjusting fineness module may come true by changing pulp concentration, adjusting the flooding water yield, changing the grit mouth, then fulfilling its three kinds function ----- washing, dehydration and screening.
(3)Features and Benefits:
1. Effectively reduce the fine sand losing quantity, and make it in the scope of 5-10%.
2. The vibrating screen utilizes polyurethane screen cloth, which has longer life compared with others and uneasy to be blocked.
3. Inner the polyurethane, strengthen the whole device service life, it can smoothly finished the
Work of condensing slime and clearing the liquid etc
4. The maximum fine grain materials quantity recovered from the total effluent is 85%, so it has
Unsurpassed technology and economic advantage compared with other equipments.
5. The find sand are recovered sufficiently, you can reduce the sedimentation basin workload and
Low its clean cost.
6. Reducing nature stock time of the fine material, they can be transferred directly and supplied to the market
7. We can design corresponding solve project according to our consumers, different requirements.
| Model | Pump | Cyclone(mm) | Vibrating Screen | Capacity(m3/h) | Weight(Kg) |
| Power(kw) | Size(inch) | Model | Deck Size(m2) | Power(kw) |
| SS-06-250 | 7.5Kw | 2" | 250 | 0.6× 1.5 | 0.9 | 2x0.75 | 10-40 | 3700 |
| SS-08-300 | 15Kw | 3" | 300 | 0.8× 2.25 | 1.8 | 2x1.5 | 40-80 | 4200 |
| SS-10-350 | 18.5Kw | 4" | 350 | 1.0× 2.25 | 2.25 | 2x1.5 | 70-120 | 4600 |
| SS-12-550 | 22Kw | 6" | 550 | 1.2× 3.0 | 3.6 | 2x2.2 | 100-200 | 7100 |
| SS-12-650 | 30Kw | 6" | 650 | 1.2× 3.0 | 3.6 | 2x2.2 | 120-260 | 7500 |
| SS-14-750 | 37Kw | 6" | 750 | 1.4× 3.0 | 4.2 | 2x3 | 180-343 | 8310 |
| SS-14-750II | 45Kw | 6" | 750 | 1.4× 3.75 | 5.25 | 2x5.5 | 230-420 | 8950 |
| SS-16-950 | 55Kw | 8" | 950 | 1.6× 3.75 | 5.25 | 2x5.5 | 250-500 | 14300 |
| SS-16-2× 650 | 55Kw | 10" | 2x650 | 1.6× 3.75 | 6.00 | 2x5.5 | 300-500 | 16700 |
| SS-18-2× 750 | 75Kw | 10" | 2x750 | 1.8× 3.75 | 6.75 | 2x7.5 | 350-600 | 19680 |
Zhengzhou Yifan Machinery Co., Ltd are the famous manufacturer of crusher and screen equipment for clients, which include mobile crusher (portable crusher), hydraulic cone crusher, jaw crusher, vertical shaft impact crusher(VSI crusher), impact crusher, vibrating screen and portable crushing plant. We not only offer clients the crushing& mining machinery with good capability and competitive price, but also supply top service and solution of the sand and gravel aggregate production line.
We have many technical experts in domestic crushing and screening filed, and possesses the powerful ability in developing the new products. Demands of clients are seen as our motility, we endlessly develop the new products with high performance, which could satisfy the demands of clients and reach the world level.
We highly regard the quality of products, pursue excelsior on the quality of products, and guarantee to produce the high quality product with strict ISO9001: 2000 quality management systems.
We have perfect after-sale service network. After strict training, the after-dale service engineer could offer clients the rapid maintenance service on demand. Moreover, we have our own foundry plant where lots of spare parts of the crushing and screening equipment are manufactured and plenty stored, which could offer clients spare parts conveniently.
In the rapid developing market our competition ability continuously enhances, our products have been broadly applied in the national key projects. In the course of construction of the national expressway network and big-sale hydropower station, we offer the marched crushing plants lots of whole set of crushing and screening product lines which could offer high quality concrete aggregate.
As the occupation ratio in domestic market increases, our products have been exporting to Russia, Mongolia, Chile, Media Asia, East Asia, Africa etc. Country and region.
We insist innovating constantly, keeping improvement of products, enhancing the reliability of products, aspire to be the global brand in the crushing and screening filed, and be deeply aware of our success is based on the success of clients.
