| Prod Model: |
AR9 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Color: |
Ral7032 Ral7035 |
| Profile: |
9-Fold Profile |
| Material: |
Cold Rolling Steel |
| Thickness: |
Front Door 2.0mm , Rear Panel 1.5mm |
| Mounting Plate: |
Zinc Coated 2.5mm |
| Protection Degree: |
IP55 |
| Impact Resistance: |
Ik10 |
| Fan Number: |
One |
| Usage: |
Electronic Monitoring System |
| Condition: |
New |
| Certification: |
RoHS |
| Type: |
Standard Cabinet |
| Installation: |
Vertical |
Product Description
AR9K metal floor stand cabinets comprise a 9-folded profile structure, un-welded at the top and bottom of the frame, with removable screws in versatility with the cabinet. Thermosetting epoxy polyester powder coating in textured
RAL7032 or PAL7035
Supply include:
9-folded profiles 4pcs/set(model: F): Hinged uprights,
Panel mounts and locking elements assembled.
Topcover and base(Model: TCB): Welded top frame,
Welded base, mounting plate fixing support.
Back panel and front door(Model: FBD): Plain door with lock, plain back panel.
Galvanised mounting plate(Model: MP)
Side panels(Model: ARSP): 2pcs side panels with accessories
Zhejiang tianqi electric Co., Ltd., with 10 years experience in electrical industry, is one of the leading manufacturer of distribution boxes and panel meters in China. Founded in China 1998, located in the beautiful land scape of the largest China bamboo sea in anji economic development zone which place is in the north of zhejiang, covers an area of 100, 000 square meters and has 500 employees.
T&j's product range consists of wall mounting enclosures, floor standing cabinets, stainless steel enclosures, plastic enclosures, terminal boxes, power distribution cabinets, floor standing modular cabinets, console systems, analog panel meters, digital panel meter, DIN rail panel meter, current transformer, shunt.
We also got the quality system certificate of CE, rosh, IP65 and ISO 9002 for our products. It has established the good commercial relations with America, west-europeam, east-Asia, Africa etc.
All kinds of electronics products and its accessories will be designed and manufactured according to the customer' s special requirement.
Sticking to the policy as "no quality, no future!
