| Prod Model: |
FY014 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Input Voltage: |
24V DC/12 VDC |
| Load Capaclty: |
4000N |
| Max Speed: |
42mm/s |
| Stroke: |
50-1000mm |
| Type Of Duty: |
S2-10min |
| Limit Switches: |
Inner |
| Operation Temperature: |
-26-65 degree |
| Protection Class: |
IP20 |
| Warranty: |
2 years |
| Certification: |
CE,ROHS,SGS |
Product Description
Furniture Linear Actuator
1) Furniture Linear Actuator
2) Used in electric sofa, multi-functional sofa, etc.
3) CE, RoHS approval
Specifications of FY014 Linear Actuator:
Name: Linear Actuator
Model: FY014
Input Voltage: 12V or 24V DC
Max Load Capacity: 4000N (4mm/s)
Max Speed: 35mm/s
Standard Stroke: 330mm
Limit Switches: Inner
Type of duty: S2-10min
Operation Temperature: -26 Centigrade ~ 65 Centigrade
Protection Class: IP43
Certification: CE/EMC+LVD, RoHS
Usage: Electric sofa, multi-functiona l sofa, etc.
For more information, pls contact us.
| Name: | Slide Linear Actuator |
| Model: | FY014 |
| Usage: | Electric Sofa, Recliner Sofa, Electric TV Lift, Electric Cabinet Lift, other Application use |
| Input Voltage: | 12v or 24v DC |
| Load Capacity: | 750N, 1500N, 4000N |
| Free Load Speed: | 35mm/s, 18mm/s, 8mm/s |
| Standard Stroke: | 50 mm --- 1000mm (Optional) |
| Installation Dimension: | S + 205mm |
| Type of Duty: | S2 -- 10 min (2 minutes work, 18 minutes rest) |
| Limit Switch: | Builtin / Inner (can not be adjust after left factory) |
| Work Temp.: | -26 to 65 centigrade |
| Protection Grade: | IP43 |
| Certificate: | CE / EMC + LVD, RoHS |
| Control Box Used: | Control 1 Linear Actuator: FYK011-1, FYK012-1, FYK015-1, FYK016-1, FYK017A |
| | Control 2 Linear Actuators: FYK011-2, FYK012-2, FYK015-2, FYK016-2 |
| | Control 3 Linear Actuators: FYK011-3, FYK012-3, FYK016-3 |
| | Control 4 Linear Actuators: FYK012-4, FYK016-4 |
| | Control 5 Linear Actuators: FYK012-5, FYK016-5 |
| | Control 6 Linear Actuators: FYK016-6 |
| Handset Used: | All FYH Series Handset, Pls contact us for detail pictures. |
