| Prod Model: |
BM-CNC-2620 |
| Glass Thickness: |
3.0-25 mm |
| Glass Sheet Size: |
2440*1830 mm |
| Max. Speed: |
120 M/Min |
| Cutting Accuracy: |
+/- 0.2 mm / 2 M |
| Sheet Weight: |
500 Kg |
| Voltage: |
380V 50Hz |
| Warranty: |
1 Year |
Product Description
cnc glass cutting table/cnc glass breaking table
Features:
Work flow: After starting the inputting machine, arms automatically suck glass
from the shelf. Under sensor controlled, glass automatically find glass edge in the X
and Y directions. After moving glass sheets to designated location, transport glass to
the CNC cutting table. Under laser sensory element guidance, use laser-reader to
get the position of the glass-sheet. Cutter will move to coordinate origin, and
automatically start to cut according to the preinstall graph.
After cutting, glass will move to the breaking table. Start break bars and to break
the glass. At this point, the whole process work is completed.
Technical Parameters:
| Model | BM-CNC-2620 | BM-CNC-3725 | BM-CNC-5033 | BM-CNC-6033 |
| Glass Thickness | 3.0-25 mm | 3.0-25 mm | 3.0-25 mm | 3.0-25 mm |
| Glass Sheet Size | 2440*1830 mm | 3660*2440 mm | 5000*3300 mm | 6000*3300 mm |
| Max. Speed | 120 m/min | 120 m/min | 120 m/min | 120 m/min |
| Cutting Accuracy | +/- 0.2 mm / 2 m | +/- 0.2 /2 m | +/- 0.2 /2 m | +/- 0.2 /2 m |
| Sheet Weight | 500 kg | 500 kg | 800 kg | 1000 kg |
| Outside Dimension | 14000*3500*850 mm | 14500*3800*850 mm | 17500*4000*850 mm | 19500*4000*850 mm |
Packaging & Shipping
Plastic Film is standard package.And Wooden Package is according to your requirement.
Each product will be carefully packed with plastic film package,to make sure it will be arrived safety.
If choose wooden package,After inspection the goods are packed in plastic film package and then carefully packed in wooden cartons.
Our Services
1. All equipments is 12 months guarantee,lifetime maintance.
2. Engineers available to service machinery overseas.
3. Make specialized solutions for client's requirements.
4. 24-Hour on line by Email , Skype ,WhatsApp or call .
5. Can get spare parts quickly from our Agency or Headquarters
Payment Terms
L/C, 30% deposit by T/T,70% spare payment L/C.
T/T, 30% deposit by T/T,70% spare payment before shipment.
Western Union
Quality Testing
Before delivery ,our engineer must make the Testing for every machine, to make sure that
our machines can work with high performance !
Jinan Bohman Machinery Co., Ltd., located in West-high Speed Railway Station, Jinan City, Shandong Province, is a high-tech enterprise specialized in the research, manufacture and sale of aluminum-plastic door & window production equipment, high and medium grades of insulating glass production equipment and CNC router. Our products sell very well in China and are exported to many foreign countries and regions. We have many experienced technical engineers and experts who have been worked in this industry for many years. We are familiar with the situation of this industry at home and abroad. We have mastered the latest technique of the similar equipment, and have got strong ability of product research and technique support.
Based on the modern technique, we have produced all kinds of aluminum-plastic door & window production equipment and high and medium grade insulating glass production equipment, with modern technology and stable performance. Our main products are saw cutting equipment, milling equipment, angle seam cleaning equipment, angle joint equipment, various specifications of vertical insulating glass production lines, glass curtain wall production lines, LJT butyl coating machines, GT03 bicomponent rubber spreading machines, compound sealing spacer insulating glass production lines and all kinds of auxiliary equipment.
By virtue of specialized production, good quality and excellent after-sales service, Bohman has got wide recognition and praise from customers at home and abroad. Since the establishment of our company, we have taken "being an honest enterprise, producing the best equipment" as our tenet and taken the quality of our products as the lifeline of our enterprise. We also focus on the research and development of energy saving and environmentally friendly products, try to make the best equipment for manufacturing aluminum-plastic doors & windows and insulating glass and make Bohman a world famous brand.
