| Prod Model: |
PA01 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Fabric Of Filter: |
Polyamide Liquid Filtration Bag |
| Size: |
as Customers' Requirements |
| Color: |
White |
| Shape: |
Cone Shape/ Funnelform |
| Usage Of Filter: |
Water Filtration |
| Micron Rating: |
0.5-800micron |
| Temperature Resistance: |
Ordinary 120 Degree |
| Relative Filtration Pore Size: |
0.5, 1,5, 10, 25, 50, 100, 200 µm |
| Airtight Method: |
Hot Melt, Reverse Sewing |
| Effective Filtration Area: |
Various Specifications |
| Usage: |
Chemical Industry |
| Motive Force: |
Gravity |
| Type: |
Polyamide Liquid Filtration Bag |
| Certification: |
SGS |
Product Description
Chemical Plant Purified Polyamide Liquid Filtration Bag
Quick Detail:
Material : PP or PE,polyester, polypropylene
Micron rating : 0.5um ~800um
Good anti-abrasion
High temperature grade
Anti-acid ,anti-alkali, chemical resistance
High porosity ,good air permeability
Laminated compound,grads counterchange
Description:
Low temperature resistance ( 88-110 ºC)
Excellent resistant to hydrolysis, acids and alkalies.
Smooth surface, more defined pore size and good air permeability
Lower fiber release, Lower density,High mechanical characteristics
Specifications:
#1-----(7"x16") -----¢180*410mm
#2-----(7" x 32") -----¢180*810mm
#3-----(4"x 8 1/4") -----¢102*210mm
#4-----(4"x 14") -----¢102*356mm
Material | PE,PP,NMO,PTFE |
| Cuff | PP Lock, Stainless steel |
| Relative filtration pore size | 0.5, 1,5, 10, 25, 50, 100, 200 µm |
| Type | various specifications |
| Airtight method: | Hot Melt, reverse sewing |
| Effective filtration area | various specifications |
| Others | special requirement of diameter and collar extension can be customized |
Notices:
1. Materials avaliable: polyester, polypropylene
2. construction: welded or sewn
3. collar type: steel ring or plastic ring
4. finishing treatment: singed, calendared, heat set
5. Size available: standard and custom size.
Technology Characteristics in Normal Temperature
Laminated compound, grads counterchange
High porosity, good iar permeability
High filtration efficiency, long service life
Anti-acid, anti-alkali(medial), chemical resistance.
Good anti-abrasion
Good price quality
Moderate temperature grade(ordinary 120°C, few items above 150-160°C)
Polyester needle felt:
The temperature resistance of PET is between 130-150°C,PE felt is most widely applied. In addition to its special properties as other needle punched felt, it also has good anti-abrasion and better price efficient rate.
Application:
1) Upholistery Furniture-Bedding: Quilt backing , Dust covers, Spring wrap ,Flanging ,Mattress covers
2)Hygiene-Medical: Surgical grown ,Face Mask, Shoes cover, Capes, Bedsheet& pillow covers
3) Agriarture-Landcape: Cropcover, Frost protection cover, Gardening fabric, Landscape fabric ,Root bag
4) Packing -Household: Non woven bag, Storage box, Wardrobe, Pillow&Duvest bags, Home Apron
