Capacitance Cabinet

Feature 1:	Real Supplier of If Melting Furnace
Feature 2:	More Than 40 Years Experience
Feature 3:	Good Quality, Competitive Price
Feature 4:	Long Performance Life
Feature 5:	Fast Melting Rate
Feature 6:	Easy to Set-up and Use
Feature 7:	Easy to Control Furnace Temperature
Feature 8:	Unique Purified Water Cooling System
Feature 9:	ISO9001 & Ce Certificates
Feature 10:	Flexable Payment Items
Type:	Metal Melting Furnace
Certification:	Ce ISO

Product Description

Introduction and Application of Coreless Medium Frequency Induction Melter
This is the device converting three phase power current into single phase intermediate frequency current and enabling metal to produce eddy current loss through electromagnetic field induction to achieve heating and melting and is applicable to melting, heating or holding of steel, copper, aluminum, zinc, tin, nickel silver and other ferrous or nonferrous metal and alloy materials, as well as heating treatment prior to forging, sintering and tube-bending forming in casting and melting industries.

Performances and features
1. Using a zero-voltage scanning soft-start mode, in any case may at any time to start or stop, will not have impact on power supply.

2. Fast smelting with low production cost; Low-pollution and environment-friendly.

3. A direct effect from the cold furnace melting. Dissolved material will be fully dumped clean. Molten material is easy to replace.

4. Power adjustment flexibility. Be able to continuously smooth adjustment. Temperature uniformity can be easily controlled. Oxidation burning less, and metal components evenly.

5. Furnace shell using cast aluminum or steel structure, small footprint; Furnace flip dump convenience, according to the need to use electric, manual, hydraulic tilting furnace and other means.

6. Designed to automatically adjust angle of inverter circuit that can automatically adjust the load impedance match, without adjustment of capacitance compensation and always run the equipment in good working condition; Power supply system diagnostic error function, easy maintenance.

Compare to peer-factories, we have below outstanding advantages:
1. Equipped with built-in circulating water cooling system, equipment can be long-term work, no cleaning needed; Will not be damaged furring electrical power components; And lengthen the using life of whole machine.

Other manufacturers require users to cool down the machine with directly tap water or groundwater; Regularly clean the water pipe of equipment with detergents; And often because of poor water quality, the equipment, furring channels, resulting in poor heat electrical components being blocked or damaged.

2. Configure automatic circuit breaker, with a reliable protection
Equipment power supply short circuit, open circuit, lack phase, power outages, discharge, and other circuit abnormalities are able to quickly and automatically cut off the power supply; In a timely manner to the equipment and network protection, to ensure the safety of the production operator.

Other manufacturers may only with simple switch or without. They asked users to protect themselves with fully functional power distribution equipment. Otherwise, once short circuit, lack phase, or other circumstances occur, because there is no protection, lead to serious accidents.

However, our equipments carry good protective function even without switch board prepared by the users.

3. We are one of the largest enterprises in the industry in China.
We are devoted to independent R&D as well as production. A rich variety of finished products and half-finished products with complete specifications and spare parts enable us to finish fast delivery. In addition, the independent after-sales department will provide follow-up services regularly as to all the products. Furthermore, many of our engineers have been engaged in the industry for over 20 years while 80% of the intermediate-frequency equipment manufacturing companies had not yet been established 15 years ago.

Furnace Capacity	Rating Power	Input Voltage	Input Phase	Input Current	Assorted Transformer	Output Voltage	Output Frequency	Melting Time	Volume	Weight
GW-0.05T	50KW	380V	3	80A	60KVA	750V	2.5KHZ	20-60Min	1.2 m³	350KG
GW-0.1T	100KW	380V	3	160A	120KVA	750V	1KHZ	20-60Min	6 m³	1500KG
GW-0.15T	100KW	380V	3	160A	120KVA	750V	1KHZ	30-70Min	6.5m³	1600KG
GW-0.2T	120KW	380V	3	192A	150KVA	750V	1KHZ	30-70Min	7.5m³	1700KG
GW-0.3T	130KW	380V	3	208A	150KVA	750V	1KHZ	30-70Min	8.5m³	1800KG
GW-0.4T	250KW	380V	3	400A	315KVA	750V	1KHZ	30-70Min	9.5m³	2300KG
GW-0.6T	350KW	380V	3	560A	400KVA	750V	1KHZ	40-80Min	11m³	2500KG
GW-0.75T	450KW	380V	3	720A	500KVA	750V	1KHZ	40-80Min	12m³	3800KG
GW-1T	600KW	380V 380V-2	3/6	960A 480A	600KVA 800KVA	750V 1300V	0.8KHZ	50-90Min	13m³	4500KG
GW-1.25T	800KW	380V 380V-2	3/6	1280A 640A	800KVA 1250KVA	750V 1300V	0.8KHZ	50-90Min	14m³	5000KG
GW-1.5T	1000KW	380V 380V-2	3/6	1600A 800A	1250KVA 1500KVA	750V 1300V	0.8KHZ	50-90Min	15m³	5500KG
GW-2T	1250KW	660V 380V-2	3/6	1120A 1000A	1500KVA 1800KVA	1300V	1300V	50-90Min	17m³	6000KG
GW-3T	1500KW	660V 380V-2	3/6	1350A 1200A	1800KVA 2000KVA	1300V	1300V	60-100Min	20m³	7000KG
GW-5T	2500KW	1000V 660V-2	3/6	2000A 1120A	3000KVA 3500KVA	1300V	1300V	60-100Min	23m³	8500KG
