| Prod Model: |
ENT workstation |
| Certification: |
SGS |
| Classification: |
Ent Examination Chair |
| Type: |
Ent Chair |
Product Description
Automatic Full configuration ENT workstation with Touch Screen
Feature:
A. Design: Have to be designed to consider with doctor's plot plan in order to reduce physical fatigue.
B. Treatment table can be turned and moved depends on user's need and it can improve the environment of treatments.
C. Marble top board: Adapted special marble avoid to soak the medicine in.
D. Endurance: Have to be adapted high quality endurance & noiseless suction motor. (less then 50dB)
E. Auto-Drainage System would be possible without suction bottle to sewage. (customized option)
F. Various Options: Unit must have a various options for each systems to cope with patients type rapidly.
1. Powerful suction system
2. Ear irrigation module
3. Thermal nystagmus stimulation
4. Compressed air system for nebulisation of medications
5. Innovative LED light module for headlight and light source
Details:
Treatment Table: The senior white marble glass, easy to scratch , elegant appearance , easy to disinfect surfaces , cleaning with a doctor writing desk ( Machine size 1830 * 720 * 810mm).
Chassis : Overall mold of production , advanced engineering plastics (ABS) materials, ergonomic shape , reasonable, environmentally friendly, and beautiful.
An independent style of positive and negative dual compressors, spray , can be used to attract , to prevent cross- infection , and greatly improve the life of the compressor.
Second, LED lights : (12V10W, condenser , non-thermal radiation , ten dimming ) adjustable height , adjustable to any angle , the amount of light can be refracted mirror with ear , nose, throat and other parts for inspection .
Third, the positive and negative pressure regulating design , adjustable spray attractive size.
Fourth, the positive and negative gauge can be observed when using the spray , the size of attraction .
Fifth, the touch buttons , generous , clean, easy to operate.
Six attract dirt bottles 2500CC, large capacity.
Seven vials with a capacity of 30CC, tampons diameter Φ90.
Eight , built-in LED cold light source : Fiber can be accessed auriscope , endoscopy , fiber optic laryngoscope , lighting rods.
Nine , spray gun: ( a flow rate of 3 ~ 9ml/min, spray taper of not less than 20 degrees ( spray device : the liquid inside the bottle gun can be configured with different liquid, can treat nasal congestion , shrink nasal , nasal congestion, throat the role of inflammation and anesthesia before surgery , etc.) .
Smoking gun : 0 ~ 1000mmHg its suction is adjustable , anti- reflux device , safety and environmental protection , easy to clean , has a suction adjustment finger holes , can be equipped with 3mm, 2.5mm of suction tube . ( Plug-in suction device can be sucked nasal secretions , wound blood clots, pus , so as to ensure a clear surgery and clean the affected area ) .
Blow Gun : pressure up to 0.26Mpa, pressure adjustment function ( can be used for ear throat blow sheets , wound drying , etc. ) .
Ten, laryngoscopy preheating device ; manual start switch , 450W low energy consumption, heating 0-180 seconds adjustable , to automatically shut down . Bake indirect laryngoscopy , nasopharyngeal mirror, the mirror temperature adaptation body temperature . ( Indirect laryngoscopy , nasopharyngoscopy can check whether the nasopharynx or larynx has retained foreign body ) .
Control system: the case of intelligent power-down feature that no action , one hour after entering the power saving mode , press any key to resume . 4 hours off automatically after 30 minutes.
Chair at automatic operation process, if you need to stop running , according to any of the operating chair bit key to exit .
All parameters are set with power protection.
When the power supply is interrupted and then restored, in addition to temporary interruption of operations carried out , the security issues will not arise .
When the machine turned on, the buzzer beeps a sound, power indicator light , then the machine automatically detects all functions are normal.
Compressor security features. ( Compressor to work more than 20 minutes , it will automatically turn off the compressor .
| STANDARD EQUIPMENT | QUANTITY | |
| 1.LED illuminating light | 1 | Imaging system: |
| 2.Spray gun (unbent 2 & bend 1) | 3 | 1 CCD/3 CCD camera |
| 3.Suction gun | 1 | 15 inch LCD monitor |
| 4.Blowing gun | 1 | Computer (17 inch LCD display/professional endoscope sofeware) |
| 5.Laryngoscope pre-heater | 1 | Pinter |
| 6.Built-in LED light source | 1 | Fiber cable |
| 7.Luxury thin film viewer | 1 | Hernia cold light cource |
| 8.Blow-off equipment system (with warning system) | 1 | |
| 9. Instrument tray | 2 | Endoscope: |
| 10.Cotton cup | 2 | Φ2.7/4mm,0° /30° otoscope |
| 11. Medical bottle | 4 | Φ2.7/4mm,0° /30° nasoscope |
| 12.Built-in waste tank | 1 | Φ8mm,70° /90° laryngoscope |
| 13.Built-in equipment recycle tank | 1 | Constant temperature rinsing system |
| 14. Doctor stool | 1 | LED headlight |
| 15. Vacuum pump | 1 | 5 inch intelligent touched contrilled |
| 16.Compressor | 1 | Patient chair |
