| Prod Model: |
ZZ5347 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Bran: |
Sinotruk Steyr |
| Allowable Passengers In Cab: |
3+3 |
| Engine Brand: |
Weicai |
| Water Tank Capacity: |
10-12cbm |
| Powder Tank Capacity: |
3-4cbm |
| Water Rated Flow: |
30L/S |
| Fire Monitor Range: |
More Than 45m |
| Tool Box: |
4-5 Set as Optional |
| Certification: |
CE |
| Volume: |
＞10000L |
| Emission Standard: |
Euro 2 |
| Transmission Type: |
Manual |
| Engine Type: |
4 Stroke |
| Payload: |
20T |
| Fuel: |
Diesel |
| Drive Wheel: |
6?á4 |
| Horsepower: |
150-250hp |
| Condition: |
New |
Product Description
Chengli Special Automobile Co., Ltd
1. We are a group company with one years quality guarantee.
2. We have advanced technology and equipments, mature experience.
3. We are leading manufacturer in China, the price of our trucks are competitive.
4. We have modern management system, the delivery time are on time.
5. We exports many trucks over the world. We have professional sales team.
Our main products:
1. Dump Truck / Tipper Truck
2. Fire Fighting Truck / Fire Truck / Fire Vehicle / Fire Engine
3. Truck with crane / Truck mounted crane
4. Oil Tank Truck / Fuel Tanker Truck
5. Water truck / Water Tank Truck / Water Sprinkler Truck
6. Concrete Mixer Truck
7. Van truck / Insulated truck/ Refrigeration truck
8. Fecal suction truck / Sewage suction truck,
9. Cement Powder Tank truck/ Bulk cement truck
10. High-altitude operation truck,
11. Self-loading garbage truck, garbage compactor truck, sealed garbage truck,
12. Semi Trailer ( flat bed trailer / skeleton trailer / dump semi trailer / side wall trailer / low bed trailer / van container trailer / warehouse trailer, etc. )
13. Pressure vessel
| Vehicle Main Dimensions | Cab type | Sinotruck steyr two row and an A/C |
| Overall dimension(L×W×H)(mm) |
10100×2500×3330 |
Tanker volume(l) | water tank 16000L or water 13000l & foam 3000L |
| Wheelbase (mm) | 4600+1350 |
| Axle number | 3 |
| Drive type | 6*4 |
| Steering type | LHD/RHD with hydraulic power steering |
| Max. Drive Speed (km/h) | 85 |
| Curb weight (kg) | 15550 |
| Chassis parameter | Chassis Model | ZZ5347 |
| Chassis manufacturer: | CNHTC |
| Front/ rear Axle loading capacity(kg) | 9000/16000 |
| Transmission | Manua 10 Forward & 2 reverse. |
| Brakes | Service brake: dual circuit compressed air brake |
| Tire | Seven units of 11.00-20 Nylon tires.(option:11.00R20) |
| Engine parameter | Brand | CNHTC |
| Model |
WD615.47
|
| Fuel type | Diesel |
| Engine Type | 6-cylinder in-line with water cooling;4-stroke direct injection;turbo-charging and inter-cooling |
| Horse Power(kw)/(hp) | 371HP |
| Displacement(ml) | 9726ml |
| Emission Standard | Euro 2 |
| Superstructure parameter | 1. equipped CB10/60 fire pump(rear)(diversion time≤35s) |
| 2. Water tanker volume: 16m3, tanker material: high quality carbon steel |
| 3. equipped with PS50 type fire monitor,(pressure:1.0MPa,flow:50L/s,shot range≥60m,rotation angle: left or right 360°,up or down-30°~80°) |
| 4. steel pump room/equipments box ,5-9 Aluminum curtain door |
| 5. other equipment: 1600mm long rows of lights in the top of cab |
