| Prod Model: |
HJG-A |
| Design: |
Glass Door |
| Product Capacity: |
6u - 14u |
| Suitable Standard: |
IEC197-2, Ein4194 |
| Type: |
Server Cabinet |
| Usage: |
Network Integration System |
| Installation: |
Vertical |
| Fan Number: |
One |
| Certification: |
ISO |
| Condition: |
New |
| Capacity: |
6u~14 |
Product Description
19 Inches Standard Wall Mount Network Cabinet
Feature:
1. Solid construction with welded frame provide good loading capacity.
2. Both glass front door and side panel have lock.
3. Top and bottom have cable inlet and inlet cover.
4. Glass is easily replaced after damaged. No need to replace the whole front door.
5. Normally the top has one fan, but we can add more according to your requirement.
6. All components are pre-installed, no need to assembled before use.
Specifications for choice:
| | Model | U | Specifications (W x D x H mm) |
| 1 | HJG-A-6406 | 6 | 600 x 450 x 341 |
| 2 | HJG-A-6408 | 8 | 600 x 450 x 430 |
| 3 | HJG-A-6412 | 12 | 600 x 450 x 610 |
| 4 | HJG-A-6414 | 14 | 600 x 450 x 700 |
Materials:
SPCC cold rolled steel
Surface finish:
Degrease, acid pickling, rust prevention and parkerizing, pure water cleaning, static electricity powder coating.
Standards:
Comply with ANSI/EIA, RS-310-D; IEC297-2; DIN41491: PART1; DIN41494: PART7; GB/T3047.2-92 standard and ETSI standard
Color:
1. Regular color: RAL9004 Black, RAL7035 Grey.
2. You can customize surface color, or choose from my color library.
